Industrial Magnetic Surface Temperature Probe (-60°C to 500°C) for Pipe & Metal Equipment | High-Accuracy German Class A PT100 RTD

Large Image : Industrial Magnetic Surface Temperature Probe (-60°C to 500°C) for Pipe & Metal Equipment | High-Accuracy German Class A PT100 RTD

Product Details:

Place of Origin:	China
Brand Name:	GME
Certification:	CE

Payment & Shipping Terms:

Minimum Order Quantity:	50pcs
Price:	USD1-USD10
Packaging Details:	cartons， pallet
Delivery Time:	7~10 working days
Payment Terms:	T/T,Western Union,,L/C
Supply Ability:	100000 pcs per Month

Contact Now

Detailed Product Description

Sensor Element:	PT100 Platinum Resistance (RTD)	Accuracy:	±0.2%
Temperature Range:	-60°C To +500°C	Probe Diameter:	15 Mm / 20 Mm
Cable Specification:	3-Core PTFE Shielded Wire	Mounting Mechanism:	High-strength Surface Magnet
Highlight:	Magnetic Surface Temperature Probe , PT100 RTD Pipe Sensor , High-Accuracy Class A RTD

Product Overview

Engineered for non-invasive, high-accuracy surface temperature monitoring of ferrous metal equipment, this industrial-grade PT100 RTD sensor combines imported German sensing elements with an ultra-strong magnetic probe housing. It eliminates the need for mechanical drilling or adhesive mounting, making it ideal for fast, non-destructive installation on motors, bearings, and piping systems.

Key Features

High Precision & German RTD Chip

Powered by imported high-accuracy German platinum resistance chips (0.2% accuracy), offering exceptional stability, fast response, anti-vibration performance, and a long service life for demanding industrial applications.

Secure Magnetic Mounting

Designed with an ultra-strong magnetic probe (15 mm / 20 mm diameter options) for instant, tool-free attachment to iron, steel, motors, bearings, and ferrous metal surfaces.

Extended Temperature Ranges

The standard variant covers −50°C to 450°C, while the high-temperature strong-magnetic variant handles extreme thermal environments from −60°C to 500°C.

Technical Specifications

Parameter	Specification
Sensor Element	PT100 Platinum Resistance (RTD)
Chip Source	Imported German RTD Chip
Accuracy	±0.2%
Standard Temp Range	−50°C to +450°C
High-Temp Variant	−60°C to +500°C (Strong-Magnetic)
Probe Dimensions	Diameter: 15 mm / 20 mm
Cable Specification	3-Core PTFE Shielded Wire (Waterproof, Oil/Chemical Resistant, Anti-Interference)
Mounting Mechanism	High-strength surface magnet for ferrous materials
Customization	Cable lengths, lead wire configurations, and probe dimensions

Customization options are available for cable lengths, lead wire configurations, and probe dimensions to suit specific installation requirements.
