PT100 Magnetic Surface Temperature Sensor with metal mesh Lead [-50...450°C]

Large Image : PT100 Magnetic Surface Temperature Sensor with metal mesh Lead [-50...450°C]

Product Details:

Place of Origin:	China
Brand Name:	GME
Certification:	CE

Payment & Shipping Terms:

Minimum Order Quantity:	50pcs
Price:	USD1-USD10
Packaging Details:	cartons， pallet
Delivery Time:	7~10 working days
Payment Terms:	T/T,Western Union,,L/C
Supply Ability:	100000 pcs per Month

Contact Now

Detailed Product Description

Temperature Range:	-50~450°C	Probe Diameter:	20mm/15mm
Probe Height:	25mm	Accuracy:	0.2%
Probe Material:	Stainless Steel/Nickel	Lead Wire:	3-core PTFE Shielded
Highlight:	PT100 magnetic surface temperature sensor , metal mesh lead temperature sensor , RTD sensor -50 to 450°C

PT100 Magnetic Surface Temperature Sensor with metal mesh Lead [-50...450°C]

Description:

PT100 Magnetic Surface Temperature Sensor use Magnetic probe, suitable for surface temperature measurement of various ferrous material equipment, with high accuracy, fast response, convenient and quick installation! This probe is magnetic and can absorb metal objects on the surface of metal, such as iron and magnetic objects, bearing cast iron and other metal objects. The temperature range of this section is -60-500 degrees, and the high temperature and strong magnetic temperature resistance is -60-500 degrees. The precision of platinum resistance is 0.2%. The wire adopts three-core PTFE waterproof, corrosion-resistant, oil-resistant and waterproof shielded wire. If other environmental dimensions are required, it can be customized. Chips imported from Germany, anti-interference, anti-vibration, stable performance, high accuracy and long service life! The size of the magnetic probe part is: Diameter: 20MM/15mm, etc. Height: 25MM, the lead wire is made according to your needs

Specification:

Typical applications: such as the surface temperature of underground water pump motors; rapid measurement of the temperature of processed parts on the production line; portable measurement of the surface temperature of outdoor objects; large-scale water pump motor bearings and outer surface temperature of bearing bushes; outer surface temperature of conveying pipes, etc.
