Portable High Frequency Induction Heating Machine
ADVANCED TECHNOLOGY
Induction heater kit adopts the latest MOSFET, IGBT power units, and frequency conversion control techniques with high efficiency, low energy consumption, and higher output power.
HEATING QUICKLY
With constant current and constant power control function, 15 kW heaters greatly optimizes the heating process of metal, realizes efficient and fast heating, and gives full play to the advantages of the product.
AUTOMATIC CONTROL
With 100% load design, induction forge can work in 24 hours without stop. Infrared temperature detector can be equipped to realize the automatic control of temperature, improve heating quality, and simplify manual operation.
EASY TO USE
With heating-insulating-cooling three stages function setting, the heating and insulating time required can get to accommodate to the batched and repeated heating situations.
SAFETY PROTECTION
With multiple status displays of overflow, over-voltage, low water, phase failure, and load malfunction, providing higher reliability and sustainability.
APPLICATION
Brazing of length 6-40mm carbide and other materials
| Specification | |
| Item Name | Induction Heating Machine |
| Input voltage | 1 phase 220V 50HZ |
| Working Voltage | 180V-250V |
| Input AC current | 15A |
| Output power | 15KW |
| Output frequency | 30-100KHZ |
| Output current | 200-600A |
| Duty cycle | 100% |
| Power factor | ≥95% |
| Cooling water pressure | 0.06-0.12 MPa 7.5L/Min |
| Cooling water flow | ≥0.5m³/Hour |
| Water temperature protection point | 40℃ |
| Weight | 27.5Kg |
| Size: | 560*230*520mm / 320*220*370mm |
