Thermocouple J / K Auto Tuning Hot Runner Temperature Controller For Plastic Injection Mold

Large Image : Thermocouple J / K Auto Tuning Hot Runner Temperature Controller For Plastic Injection Mold

Product Details:

Place of Origin:	China
Brand Name:	GME
Certification:	CE

Payment & Shipping Terms:

Minimum Order Quantity:	50pcs
Packaging Details:	cartons， pallet
Delivery Time:	7~10 working days
Payment Terms:	T/T, Western Union, MoneyGram, L/C
Supply Ability:	100000 pcs per Month

Contact Now

Detailed Product Description

Power Source:	Electric	Temperature Range:	-200~650℃
Voltage:	12-480V	Current:	0-20mA.4-20mA
Input Type:	K.J.R,S,B,E,N.T	Volt:	0-5V.1-5V
RTD:	PT100.CU50	Feature:	Economical
Operating Temperature:	0~50℃	Sampling Period:	0.5s
Highlight:	Auto Tuning Hot Runner Temperature Controller , Thermocouple J Hot Runner Temperature Controller , Thermocouple K Mold Temperature Controller

Thermocouple J or K Auto Tuning Hot Runner Temperature Controller for plastic injection mold

1. Specification

Power Supply	1-phase 3-wire, 240Vac, 50/60Hz 3-phase 4-wire, 240Vac, 50/60Hz 3-phase 5-wire, 380Vac, 50/60Hz	Mainframe	Black
Power Supply		Control Module	HRTC-A / HRTC-B / HRTC-C / HRTC-G
Sensor Type	Thermocouple J or K	Module Qt'y	16
Temperature Control	0~450℃(32~842℉)	Control Mode	Auto-PID / Manual
Output Type	Zero Cross / Phase Angle	Control Accuracy	±0.1%F.S
Connector Type	Customized	Load Capacity	15A, 3600W
Wiring Mode	Customized	Storage Temperature	-20~70℃(-4~158℉)
Working Temperature	0~55℃(32~131℉)	Working Humidity	10~80%RH(No condensing)

Light Handy and Easy to use

• Wide power supply range, AC85~400V• There are 2, 4, 6, 8, 10, 12, 24 zones for customers to select.
• Thermocouple input protection, prevent module damaged by mis-connection • Thermocouple & heater inverse protection, prevent thermocouple damaged by mis-connection
• Soft-start mode, avoid the humidity make the heater burn out

Alarm when the followings occurred

Ultra-high or ultra-low Temperature

Thermocouple break, short or inverse

Thermocouple is out of its position

Heater break, short or overload

Output device is damaged6. Over voltage of power supply

Protection activated in the following situations:

Over voltage self-protectd, max.AC500V2. Thermocouple input protection, prevent module damaged by misconnection
Thermocouple & heater inverse protection, prevent thermocouple damaged by misconnection
Soft-start mode, avoid the moisture make the heater burn out
Heater dehumidified time can be extended
