High potention sacrificial magnesium anode Mg balance ISO9001

China High potention sacrificial magnesium anode Mg balance ISO9001 supplier
High potention sacrificial magnesium anode Mg balance ISO9001 supplier High potention sacrificial magnesium anode Mg balance ISO9001 supplier

Large Image :  High potention sacrificial magnesium anode Mg balance ISO9001

Product Details:

Place of Origin: China
Brand Name: GME
Certification: ISO9001
Model Number: OEM

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Packaging Details: Standard Export Packing
Delivery Time: 7-15days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Verified Supplier

China

  • Product Details
Detailed Product Description
Material: Mg Alloy, Magnesium Metal Chemical Composition: Mg Balance
Application: Cathodic Protection Product Technology: Casting
Customized Or Not: Customized Size Available Type: As Required Or As Drawing
High Light:

sacrificial anode rod

,

Magnesium Alloy Sacrificial Anode

High potention sacrificial magnesium anode manufacturers



GME Magnesium anodes are produced in a variety of shapes and sizes for use in anti-corrosion protection of such projects are oil pipelines, gas pipelines, water supply pipes and drain-pipes, underground cables, chemical plants, communication, harbors, watercrafts and reservoir strobe.





Cast sacrificial magnesium anode



Dimensions



C Type

High potention sacrificial magnesium anode Mg balance ISO9001

















Type

Diameter

(mm)

Weight High Potential L(mm) AZ63 anode L(mm)
C25 75 2.56 336 325
C36 114 3.70 202 193
C41 114 4.20 230 220
C77 110 7.80 431 412
C100 110 10.20 560 536
C145 146 14.70 494 472
C227 178 22.90 520 497
C274 114 28.20 1528 1462



D Type

High potention sacrificial magnesium anode Mg balance ISO9001

















Type Weight(Kg) Specification
W(mm) H(mm) L(mm)
9D2 4.082 69.90 76.20 549.30
14D2 6.350 69.90 76.20 850.90
20D2 9.072 69.90 76.20 1212.90
9D3 4.082 88.90 95.30 352.40
17D3 7.711 88.90 95.30 641.40
32D5 14.515 139.70 146.10 504.80
48D5 21.772 139.70 146.10 765.20
1.5kg 1.50 80.00 70.00 190.00
2.5kg 2.50 80.00 70.00 300.00



High potention sacrificial magnesium anode Mg balance ISO9001S Type Type Weight Specification
W(mm) H(mm) L(mm)
3S3 1.4 76.20 76.20 114.30
5S3 2.5 76.20 76.20 190.50
9S2 4.1 50.80 50.80 685.80
9S3 4.1 76.20 76.20 342.90
17S2 7.7 50.80 50.80 1295.40
17S3 7.7 76.20 76.20 647.70
20S2 9.1 50.80 50.80 1524.00
32S3 14.5 76.20 76.20 1143.00
32S5 14.5 127.00 127.00 533.40
40S3 18.1 76.20 76.00 1524.00
48S5 21.8 127.00 127.00 787.40
60S4 27.2 101.60 127.00 1524.00





Pictures

High potention sacrificial magnesium anode Mg balance ISO9001



High potention sacrificial magnesium anode Mg balance ISO9001
