Wuhan Global Metal Engineering Co., Ltd
The pioneer manufacturer of heaters & sensors
 |
| Place of Origin: | Wenzhou, China |
| Brand Name: | GME |
| Certification: | CCC,IEC,UL,etc |
| Minimum Order Quantity: | 50M |
|---|---|
| Packaging Details: | cartons |
| Delivery Time: | 5-8 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 10000000 Meter/Meters per Month |
| Type: | Insulated | Application: | Inter Connection |
|---|---|---|---|
| Conductor Material: | Copper | Conductor Type: | Stranded |
| Insulation Material: | FEP | Rated Temperature: | 200 °C |
| Highlight: | high temperature electrical wire,high temperature insulated wire |
||
1. Short Description
| Type: | Insulated | Application: | Inter connection | Conductor Material: | Copper |
| Conductor Type: | Stranded | Insulation Material: | FEP |
| Packaging Details: | in box, in coil, roll, PE film, polybay, nylon |
| Delivery Detail: | Shipped in 20 days after payment |
FEP(Fluorinated ethylene propylene) insulated wire have an excellent resistance to chemicals, oil and gasoline. The behaviour against environmental influences such as ozone, UV radiation, humidity and high temperature fluctuations is excellent. The stranded wires are non-flammable and environmentally neutral. FEP is very similar in composition to the fluoropolymers PTFE (polytetrafluoroethylene) and PFA (perfluoroalkoxy polymer resin) FEP and PFA both share PTFE's useful properties of low friction and non-reactivity, but are more easily formable. FEP is softer than PTFE and melts at 260 °C; it is highly transparent and resistant to sunlight.
Wire Type
UL1330/UL1331/UL1332 - Hook up, Insulated Wire
Application
Used for wiring of electric heaters, appliances, thermocouples, gas igniters, electrical and electronic components, and other products up to 200℃, which made it resistant to moisture, and acids.
Single conductor FEP 200 degree appliance wiring material widely used in all internal fixture wiring applications
Key Features
•Conductor : 28-10 AWG, solid or stranded,tinned copper, with other platings available for special application needs, in compliance with UL758
•Insulation : FEP insulated
•Uniform thickness of wire to ensure easy stripping and cutting.
• Very Good Mechanical Strength and Abrasion Resistance
• Excellent Electrical Insulating Properties
• Excellent Thermal Stability
• Resistant to Chemicals and Solvents
• Excellent Resistance to Ozone and Oxidation
• Good Flexibility
• Good Lubricity (low coefficient of friction)
Rated Temperature: 200°C
Rated Voltage: 300V
The cable can be customized according to customer requirements
All of the above products can provide follow-up processing services (eg: cutting, strapping, crimping, etc)
We can supply wire harness assembly.
