| Product Name: | Cartridge Heater | Application: | Heating Instrument |
|---|---|---|---|
| Tube Material: | SS304;SS316,SS321 | Shape: | Right Angel |
| Conductor: | Pure Nickel | Length: | 15mm - 10m |
| Wattage: | 0.5-15KW | ||
| Highlight: | cartridge heater with thermocouple,cartridge immersion heater |
||
High Temperature Stainless Steel Right Angel Cartridge Heater with Pure Nickel Conductor Wire
Description:
High Temperature Stainless Steel Right Angel Cartridge Heater with Pure Nickel Conductor Wire are cylindrical electrical heating elements. Protected with a stainless steel sheath (the sheath material also could be others as your design, for example incoloy, titanium, ceramic, ptfe, steel etc.) , their watt density can reach 25 W/cm2 and their operating temperature can go up to 800°C (1472°F).
Cartridge heater is usually used for heating up solids such as injection presses heating plates or various tools, it also can be used for heating up water of gases under certain conditions. Widely used for manufacturing plastic and rubber parts in the car industry or in the food processing industry, etc
It is usually used in heating applications by inserting into metal blocks via a series of drilled holes. Cartridge heaters are manufactured in two basic forms - high density and low density.
High Temperature Stainless Steel Right Angel Cartridge Heater with Pure Nickel Conductor Wire are also commonly found in the chemical, electronics, medical equipment, packing and nuclear industries
Specifications:
|
Heat intensity |
Not exceeding 30Wcm2 (advisable) |
|
Power source |
electric |
|
Tube diameter: |
Φ3mm-Φ30mm |
|
Reisistance wire element |
Pure Nickel |
|
Wire options |
,silicone high temperature frberglass |
|
Insulation Mgo |
Mgo |
|
Thermocouple type |
K/J |
|
Power |
Depends on the dimension |
|
Escape of current (when cold) |
<=0.1mA a 242 v. |
|
Insulation (when cold) |
5 Min Ohmios 500 Watts minimum |
|
Dielectric strength |
1500v. 1/seg |
|
Working temperature |
750ºG max. |
|
Tolerance of length |
+/-1.5% |
|
Tolerance of diameter |
-0.01 a -0.06 m/m |
|
Tolerance of cut of connexion |
+/-15 mlm |
|
Power tolerance (w) |
5 % - 10 % |
|
Cold areas |
Depends on length and diameter 5-25mm |
Applications:
Usually, cartridge heaters are used to heat solids such as injection presses heating plates or various tools; On the other hand, they are also used for heating up water and gases under certain conditions. Especially, it is widely used in automotive industry. Cartridge heaters are also commonly found in the chemical, electronics, medical equipment, packing and nuclear industries:
1. Packaging industry - Heating of cutting bars, hot stamps
2. Food Service: Steamers, Dish Washers,
3. Injection molding machine - Internal heating of nozzles
4. Hot runner systems - Heating of manifolds
5. Medical- Dialysis, Sterilization, Blood Analyzer, Nebulizer, Blood/Fluid Warmer, Temperature Therapy
6. Laboratories - Heating of analytical equipment
5.4 Competitive Advantage:
Right angel cartridge heater with stainless hose over high temperature wire is the strongest lead protection for abrasion, which offers good flexibility, easy moving and flexing application.
1. GME specialized in manufacturing high density cartridge heaters.
2. Maximum wattage density: 30w/cm²
3. Minimum diameter:3mm.
4. Insulating material can be resistant to the high temperature of 400 degree.
5. Our product can meet IP65 waterproof
6. All lead wires are pure nickel
