5 Pin Aviation Metal Electrical Connector 16-22AWG

Large Image : 5 Pin Aviation Metal Electrical Connector 16-22AWG

Product Details:

Place of Origin:	China
Brand Name:	GME
Certification:	CE
Model Number:	no

Payment & Shipping Terms:

Minimum Order Quantity:	500
Price:	USD0.8-USD1.0
Packaging Details:	paper carton, vacuum packaging
Delivery Time:	25days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	50000pc per month

Contact Now

Detailed Product Description

Material:

Metal

Color:

Silver

Highlight:

5Pin Aviation Metal Electrical Connector

22AWG Aviation Metal Electrical Connector

Aviation Electric Heater Connector

5 pins or 6 pins Aviation Metal Electrical Connector

Application

Aviation waterproof connectors are widely used in sensor& actuator, Device NET, Motor servo, Digital camera,Railway process control, Electronics, Automotive, Transportation, Medical, Oil Exploration, Aviation, Marine Exploration Industries, Metro Device,Bank Device, Network project and so on.

Coupling: Threaded coupling2. The shell material:
Zinc alloy(nickel plated)
Insulator material: Bakelite/PBT
Contact material: Nickel (silver/gold plated)

Features & Advantages

			Way
			5 way

			Color
			Sliver white

			Sealed/Unsealed
			sealed

			Materials
			Metal

			Wire Size
			16-22AWG

			Operating Temperature range
			-40~120

			Contact resistance
			Initial8m Max.after durability tests16m Ma

			Leak current

			Initial50kPa Min.after durability tests30kPa Min.

			Insulation resistance
			100M Min.

			Seal
			Initial50kPa Min.after durability tests30kPa Min.

			Design Tooling
			Sending us samples or drawing to design it.

			Style
			Aftermarket replacement of brand auto connectors

			MOQ
			100 units/lot

			Delivery Time
			About 7-10 days after get your payment

Tag:

Contact Person: Mr. Frank

Tel: 15058960276

Fax: 86-27-86653728
