Titanium Submersible Water Tubular Immersion Heater Heating Element

Hot sale titanium submersible water tubular immersion heater heating element


Description:

Hot sale titanium submersible water tubular immersion heater heating element are screwed directly through a threaded opening in a tank wall or through a matching pipe coupling or half coupling. Sizes of screw plug heaters are available with 1”, 1-1/4”, 1-1/2”, 2”, 2-1/2" pipe threads. A wide selection of screw plug sizes, kilowatt ratings, voltages, sheath materials, terminal enclosures and thermostats makes these compact heaters ideal for all types of applications.

Specification:

The heating pipe adopts stainless steel tube coat, modified magnesium oxide powder, high-performance

nickel-chromium electrothermal alloy wire and other materials. This series of products can be widely

used in heating water, oil, air, nitrate solution, acid solution, alkali solution and low-melting point metals

(aluminum, zinc, tin, Babbitt alloy). It has good heating efficiency, uniform temperature, high temperature

resistance, corrosion resistance and good safety performance.

1.Vottage :220/380V

2.Wattage :6KW

3.Length: 600MM

4.Thread: 1 1/2"

5. Material: Stainless steel, AISI 321 304, SUS 316L







Application:

Screw Plug Immersion Heaters are used for heating liquids and gases in a variety of processes. These heaters are ideal for process water heating and freeze protection. All types of oils and heat transfer solutions can also be heated using these compact, easily controlled units. The direct immersion method is energy efficient and well suited for many applications.

• Hot Water Storage Tanks

• Warming Equipment

• Preheating all Grades of Oil

• Food Processing Equipment

• Cleaning and Rinsing Tanks

• Heat Transfer Systems

• Process Air Equipment

• Boiler Equipment

• Freeze Protection of Any Fluid
