Steatite Ceramic Terminal Block For Flexible Heater

Large Image : Steatite Ceramic Terminal Block For Flexible Heater

Product Details:

Place of Origin:	China
Brand Name:	GME
Certification:	CE,
Model Number:	no

Payment & Shipping Terms:

Minimum Order Quantity:	500
Price:	USD0.8-USD1.0
Packaging Details:	paper carton, vacuum packaging
Delivery Time:	25days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	50000pc per month

Contact Now

Detailed Product Description

Material:

Ceramic

Color:

White

Highlight:

Steatite Ceramic Terminal Block

Terminal Block For Flexible Heater

Steatite Ceramic Flexible Heater Components

electrical ceramic connector steatite ceramic terminal block for flexible heater

Description:

Smooth ceramic (high quality ceramic)is made of hot press injection technic, size is very accurately. We can produce and install according to customers demand size , joints have material as nickel-plate copper or coper, stainless steel screw, surface as zinc plating or nickel-plate treatment etc, it can endure high temperature as 425 C degree, Voltage 250V-450V, Current 10A-30A . Our products are made not-standard with high quality , it can be customerized by your request .


			Performance


			Item
			Index
			Unit
			Steatite ceramic
			95 Al2O3
			96 Al2O3


			Physical Characteristics
			Bulk density
			g/cm3
			2.7
			3.6
			3.6


			Water absorption
			%
			0
			0
			0




			Mechanical Characteristics
			Flexural strength
			Mpa
			145
			320
			340


			Hardness Vickers
			Gpa
			5.7
			12.2
			13.5


			Elastic modulus
			Gpa
			120
			280
			320


			Poisson’s ratio
			-
			0.21
			0.22
			0.23


			Thermal Characteristics
			Linear expansion coefficient
			20-5000C 10-6/0C
			7.9
			7.1
			7.2


			Thermal conductivity
			w/(m.k)
			2.5
			16
			24


			Specific Heat
			*10-3J/(kg*K)
			0.75
			0.78
			0.78


			Electrical Characteristics
			Dielectric constant(1MHZ)
			-
			6.2
			9
			9.4


			Dielectric loss angle
			*10-4
			18
			15
			5


			Dielectric strength
			*106V/m
			18
			12
			15




Application:

Electric Ceramic Connector is widely used in high temperature enviroment, kinds of connection terminal space of severe demand.

Tag:

Contact Person: Mr. Frank

Tel: 15058960276

Fax: 86-27-86653728

Other Products

High Density 95% MgO Ceramic Tube For Thermocouple Protection

Material: Magnesium oxide ceramic

Color: White / Ivory

Bores: Single,two,four or multi bores

Shape: Round, square, rectangular, oval

MgO Ceramic Top Bottom Spacer For Making Cartridge Heaters

Material: Magnesium oxide ceramic

Color: White / Ivory

Bores: Single,two,four or multi bores

Shape: Round, square, rectangular, oval

Durable And Heat-Resistant Ceramic Terminal Block For Heaters

Usage: Wiring of heater power and thermocouple wiring in high temperature locations

Insulating material: Ceramics

Size: Customzied

Surface: White glazed

SUS304 / 321 / 316L Threaded Corrugated Hose Pipe Sleeve For Cable Protection

Material: Stainless steel SUS304,321,316L

Inner diameter: 3-12.7mm

Length: Customized

Surface: Bright

Copper Conductivity SC Terminal Connector Cable Lugs Car Battery Cable Crimping Terminals

Power Source: Electric

Temperature range: -200~650℃

Voltage: 12-480V

Probe material: Stainless Steel or Nickel

Steatite Ceramic Terminal Block For Flexible Heater

Steatite Ceramic Terminal Block For Flexible Heater

Steatite Ceramic Terminal Block

Terminal Block For Flexible Heater

Steatite Ceramic Flexible Heater Components

Angle Type High Temp Silicone Plugs,

Heaters High Temperature Silicone Plugs,

Steatite Housing Ceramic Terminal Block

Performance
Item	Index	Unit	Steatite ceramic	95 Al2O3	96 Al2O3
Physical Characteristics	Bulk density	g/cm3	2.7	3.6	3.6
Physical Characteristics	Water absorption	%	0	0	0
Mechanical Characteristics	Flexural strength	Mpa	145	320	340
	Hardness Vickers	Gpa	5.7	12.2	13.5
	Elastic modulus	Gpa	120	280	320
	Poisson’s ratio	-	0.21	0.22	0.23
Thermal Characteristics	Linear expansion coefficient	20-5000C 10-6/0C	7.9	7.1	7.2
	Thermal conductivity	w/(m.k)	2.5	16	24
	Specific Heat	10-3J/(kgK)	0.75	0.78	0.78
Electrical Characteristics	Dielectric constant(1MHZ)	-	6.2	9	9.4
	Dielectric loss angle	*10-4	18	15	5
	Dielectric strength	*106V/m	18	12	15
