Refractory 99% Al2O3 Ceramic Alumina Mullite Magnesia Ceramics Tubes

Name: Refractory 99% Al2O3 Ceramic Alumina Mullite Magnesia Ceramics Tubes
Brand: Wuhan Global Metal Engineering Co., Ltd
SKU: Mgo rod
Price: 0.002 USD
Availability: InStock

$Refractory 99% Al2O3 Ceramic Alumina Mullite Magnesia Ceramics Tubes$

$Refractory 99% Al2O3 Ceramic Alumina Mullite Magnesia Ceramics Tubes$

Large Image : Refractory 99% Al2O3 Ceramic Alumina Mullite Magnesia Ceramics Tubes

Product Details:

Place of Origin:	China
Brand Name:	GME
Certification:	CE
Model Number:	Mgo rod

Payment & Shipping Terms:

Minimum Order Quantity:	500pcs
Price:	USD$0.002/pc
Packaging Details:	paper carton, wooden carton
Delivery Time:	30days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000pcs per month

Contact Now

Detailed Product Description

Material:	Magnesium Oxide Ceramic	Color:	White / Ivory
Bores:	Single,two,four Or Multi Bores	Shape:	Round, Square, Rectangular, Oval
Usage:	Works As Refractory Material
Highlight:	Magnesia Ceramics Tubes , 99% Al2O3 Ceramics Tubes , Refractory Ceramic Alumina Tubes

Refractory 99% Al2O3 Ceramic Alumina Mullite Magnesia Ceramics Tubes

Description:

Alumina ceramic is a kind of structural ceramics, with insulation resistance, voltage resistance, high strength, good thermal conductivity, dielectric loss, stable electrical performance characteristics. Used in electronic ceramic substrates, ceramic electrical insulation, vacuum devices, devices porcelain, spark plugs and other products.

Feature:

A variety of specifications available
Satisfy various technical request
Lower medium spoilage
Good insulation performance and high temperature resistance
Stiffness texture
Used in all electric products, electric heating products and wear resistant machinery parts

Material	85 Al2o3	95 Al2o3	99.7 Al2o3
Al2o3	0.85	0.94	0.996
Fe2o3	≤ 1.0	≤ 0.5	≤ 0.3
Density: g / cm3	3.4	3.6	3.85
Vickers Hardness	≥ 8.6	9	9
Water Absorption:%	≤ 0.2	≤ 0.085	≤ 0.01
Refractoriness:°C	1200 °C	1600 °C	1800°C
Flexural Strength:Mpa	180	240	280
Wear Rate( at room temperature, erosion, 100 grinding)%	≤ 3	≤ 1	≤ 0.5

$Refractory 99% Al2O3 Ceramic Alumina Mullite Magnesia Ceramics Tubes 0$
