FeCrAl Alloy OCr25Al5 Electric Resistance Heating Wire

Large Image : FeCrAl Alloy OCr25Al5 Electric Resistance Heating Wire

Product Details:

Place of Origin:	China
Brand Name:	GME
Certification:	CE, RoHS
Model Number:	K type

Contact Now

Detailed Product Description

Model Name:	0Cr25Al5	Density:	7.4g/cm3
Color:	Silver White/bright	Size:	1.0mm
Melting Point:	1500℃	MOQ:	40kg
Package:	Roll Or On Spool	Chemical Composition:	Iron Chrome Aluminum
Application:	Heating
Highlight:	OCr25Al5 Electric Resistance Heating Wire , FeCrAl Alloy Electric Resistance Heating Wire , RoHS K Type Thermocouple Components

FeCrAl alloy 0cr25al5 OCr25Al5 electric resistance heating wire

Description:

FeCrAl alloy 0cr25al5 OCr25Al5 electric resistance heating wire

FeCrAl alloy has the characteristic of high resistivity,low temperature resistance coefficient,high operating temperature,good anti-oxidation and anti-corrosion under high temperature.

It is widely used in industrial furnace, household appliances, industry furnace, metallurgy, machinery, aircraft, automotive, military and other industries producing heating elements and resistance elements.

Specification:

Size dimension range:

Wire: 0.01-10mm

Ribbons: 0.05*0.2-2.0*6.0mm

Strip: 0.05*5.0-5.0*250mm

Bar:10-50mm

FeCrAl alloy series: OCr15Al5,1Cr13Al4, 0Cr21Al4, 0Cr21Al6, 0Cr23Al5, 0Cr25Al5, 0Cr21Al6Nb,0Cr27Al7Mo2, and etc.

FeCrAl Alloy OCr25Al5 Electric Resistance Heating Wire 0

Application:

1) Heating – Gas burners for ovens
2) Cooling – Freezers
3) Engine protection – Temperatures and surface temperatures
4) High temperature control – Iron casting
