Wuhan Global Metal Engineering Co., Ltd
The pioneer manufacturer of heaters & sensors
 |
| Place of Origin: | China |
| Brand Name: | GME |
| Certification: | CE |
| Minimum Order Quantity: | 50pcs |
|---|---|
| Packaging Details: | cartons， pallet |
| Delivery Time: | 7~10 working days |
| Payment Terms: | T/T, Western Union, MoneyGram, L/C |
| Supply Ability: | 100000 pcs per Month |
| Power Source: | Electric | Dimension: | Customized |
|---|---|---|---|
| Voltage: | 12-480V | Sheath Material: | Stainless Steel Or Nickel |
| Style: | K, J, | Lead Wire: | Copper, , Fiberglass Silicon |
| Insulation Material: | MgO | Heating Element: | Nichrome Resistance |
| Screw Threads: | Available | Flange Washer: | Available |
| Connection: | Screw Fitting | ||
| Highlight: | electric immersion heater,Cast In Heaters |
||
Electric Heating Element Stainless Steel Mica Band Heater for Extruder
Description:
1) GME Ceramic Band heaters are designed and manufactured out of 8 years of experience, for superior performance and life expectancy.
2) Ceramic band heaters primarily used for Plastic Processing machinery, depending upon applications, these heaters come with outer heat saving insulation covers, which provides the best combination of physical strength, high emissivity & good thermal conductivity to heat cylindrical parts, good for sheath temperature up to 5000C along with Energy Saving.
Specification:
Nominal Wall Thickness Premium Heat : ½"
Power Saver : ½" + 5/8" (Outer Insulation)
Power Saver PLUS :½" + 1.5" ( Outer Insulation)
Connection Fiber Glass Insulated- Metal Braided Flexible Cable (std. 12" long) mounted on rigid screw post terminals
|
Voltage
|
≤480V
|
||
|
Working temperature
|
0~400℃
|
||
|
Power
|
0.5-3.5w/cm2
|
||
|
Power deviation range
|
±5%
|
||
|
Insulation resistance
|
≥100 MΩ
|
||
|
Withstand voltage
|
1500V/min
|
||
|
Mini diameter
|
30mm
|
||
|
Termination Style
|
plug, ceramic block, screw or lead wire
|
||
|
Gap Locking Mechanism Type
|
Flange, Barrel Nuts or None
|
||
|
Holes availability
|
Customer- Design
|
||
Application:
1.Plastic Injection Molding Machines
2.Plastic Extruders
3. Oil Reclamation Equipment
4. Food and Candy Extruders
5. Drum Heating
6. Extrusion Dies
7. Holding Tanks
8. Blow Molding Machines
9. Food Service Warming
10. Hot Runner Molds
