Wuhan Global Metal Engineering Co., Ltd
The pioneer manufacturer of heaters & sensors
 |
| Place of Origin: | Wuhan, China |
| Brand Name: | GME |
| Certification: | ISO9001/ CE, country required certificate |
| Minimum Order Quantity: | 10 pcs |
|---|---|
| Packaging Details: | Standard Export Packing |
| Delivery Time: | 7~20 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per Month |
| Usage: | Industrial | Temperature Range: | -200 ~ 420 Degree Centigrade |
|---|---|---|---|
| Installation Method: | Fixed Screw Installation | Accuracy: | Class 1 |
| Resistance Type: | Platinum Thermal Resistance | Index Number: | PT100 |
| High Light: | temperature sensor rtd,temperature sensor rtd pt100 |
||
PT100 RTD temperature sensor
1. good quality
2. short lead time
3. high accuracy
1. High precision temperature sensor
Thermal resistance (thermal resistor) is most commonly used in alow temperature region. It is based on the characteristic of resistance is changing with increasing temperature for temperature measurement.
They normally work as a temperature sensor. They are used together with temperature displays and controls to detect and control the temperature of gas, liquid or solid surface. Thermal resistance contains temperature sensor, fixing parts and junction box.
2. Advantages
•Advanced industrial grade waterproof design, high-strength aluminum junction box
•With a standard junction box and a variety of large and small junction box selection
•Can be customized according to IEC standard IEC584
3.Application for temperature sensor
Thermocouples are widely used in science and industry; applications include temperature measurement for kilns, gas turbine exhaust, diesel engines, and other industrial processes. Thermocouples arealso used in homes, offices and businesses as the temperature sensors in thermostats, and also as flame sensors in safety devices for gas-powered major appliances.
4. Product specifications
| Specifications |
| Name: Fixed threaded thermal resistance PT100 |
| Measuring range: -200 ~ 420 degree centigrade |
| Protecting tube material: 304 |
| Installation method: fixed screw installation |
| M27* |
| Diameter: 16mm |
| The total length: 300mm/225mm/250mm/350mm/400mm/450mm |
| Insert depth:150mm/75mm/100mm/200mm/250mm/300mm |
5. Sizing and wiring
| d | M | h | s | D0 | Nominal pressure |
| Φ10 |
M27*2 G3/4” |
32 | 32 | Φ 40 |
10KPa |
| Φ12 | |||||
| Φ 16 | |||||
| Φ 20 |
M33*2 G1” |
35 | 36 |
Φ 48 |
