Wuhan Global Metal Engineering Co., Ltd
The pioneer manufacturer of heaters & sensors
 |
| Place of Origin: | China |
| Brand Name: | GME |
| Certification: | ISO9001 |
| Model Number: | OEM |
| Minimum Order Quantity: | 10pcs |
|---|---|
| Packaging Details: | Standard Export Packing |
| Delivery Time: | 7-15days |
| Payment Terms: | D/A, L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000pcs/month |
| Power Source: | Electric | Model Number: | Coil Heater |
|---|---|---|---|
| Dimension(L*W*H): | Customized | Voltage: | 220-380 V |
| Certification: | ISO And CE | Warranty: | 1 Year |
| Highlight: | Electric Coil Heaters,coil heater with thermocouple |
||
hot runner coil nozzle heater with K / J thermocouple straight type heater
Coil heater: 110/120V,100W/150W/200W ,15.8/16/20mm and height 12.7mm,with k type thermocouple and ground wire, with 5 feet black kevlar sheath and fully black XLR male plug
12VDC,70W ,15.8/16/20mm and height 12.7mm,with k type thermocouple and ground wire, with 5 feet black kevlar sheath and fully black XLR male plug
The flat coil heater: 110/120V,100W/150W/200W ,8/9/10mm ID and 25/26mm OD ,with k type thermocouple and ground wire. with 5 feet black kevlar sheath and fully black XLR male plug
12VDC, 70W ,8/9/10mm ID and 25/26mm OD ,with k type thermocouple and ground wire. with 5 feet black kevlar sheath and fully black XLR male plug
Technical key features:
| Sectional area | 3X3,4.2X2.2,4X2,4X2.7,4X2.5 3.3 X 3.3 3.5 X 3.5 4 X 4,2.2X1.3 |
| Minimum ID | 8mm |
| Sheath Material | SS304,SS310 |
| Insulation Material | High Pure MgO |
| Resistance Wire | Cr20Ni80 |
| Maximum Sheath Temperature | 700°C |
| Die Electrical Strength | 800V A/C |
| Insulation | > 5 M W |
| Dimensional Tolerance | Coil I.D + 0.1 to 0.2mm// Coil Length + 1mm |
| Wattage Tolerance | + 10% (+ 5% Available Upon Request) |
| Voltage | 12V~380V |
| Wattage | 70W~1000W |
| Build-in thermocouple power | without or with J/K thermocouple |
| Sheath's length | 500/1000/1200/1500/2000mm |
| Available sheath | nylon,metal braided,fiberglass ,silicone rubber, kevlar |
| Sheath's color | standard is black,other color is also available |
| Connector | without or with 5 pin xlr,4 pin min xlr connector |
| Connector' color | silver or fully black |
Design Features:
1. High temperatures resistance
2. Unheated straight section
3. Precise temperature control 4. Fast response
5. Choice of lead orientation 6. Choice of lead protection
7. Longer heat lifetime 8. Round, square and rectangular cable
9. High watt densities 10. Rugged, durable construction
11. Available with built-in thermocouple 12. Made to customers' requirements
Typical Applications:
1. Injection moulding machine nozzle 2. Hot runner nozzles & Bushings
3. Packaging machineries 4. Hot runner injection moulds
5. Injection & Blow moulding machine nozzles 6. Hot runner manifolds
