Introduction

In many industrial piping systems, installing traditional thermowells by drilling holes or welding bosses is highly restrictive. It introduces risks of media leakage, pressure drops, and expensive downtime—especially in high-pressure, hazardous, or pre-existing pipelines.

Our U-Bolt Pipe Clamp Thermocouples / RTDs deliver a premium, non-intrusive solution. By clamping directly onto the exterior of the pipe, this sensor provides highly accurate, real-time surface temperature tracking without disrupting your process or damaging your piping integrity.

Key Product Features

• Zero-Drilling & Non-Intrusive Design: Eliminates the need for pipe penetration or welding, completely removing the risk of process contamination or leaks while drastically cutting down installation labor costs.

• Optimized Surface Contact: Features a rugged, curved mounting block tailored to match specific pipe diameters, ensuring maximum surface contact and superior thermal response.

• Heavy-Duty Aluminum Junction Box: Equipped with a weatherproof cast aluminum terminal head that protects internal connections against harsh ambient environments, moisture, and dust.

• Thermal Isolation Extension Neck: Built with a dedicated extension stem between the pipe clamp and the terminal head, shielding the junction box from extreme process heat to prolong sensor life.

• Tailored Configurations: Available in multiple calibrations (Type K, J, E, or Pt100 RTD) and fully customizable U-bolt sizes to fit any standard industrial pipe schedule.

Typical Applications

• Chemical & Petrochemical Processing: Monitoring hazardous, highly corrosive, or toxic fluids where pipe penetration poses severe safety risks.

• Power Plants & Steam Lines: Real-time thermal tracking of high-pressure steam pipes without altering structural certifications.

• HVAC & Large-Scale Chilled Water Systems: Efficient temperature management in commercial heating and cooling fluid lines.

• Food, Beverage & Pharmaceutical Processing: Ideal for sanitary environments where inner-pipe stagnation and bacterial growth must be prevented.

• Retrofitting & Temporary Testing: Quick deployment for energy audits, system troubleshooting, or localized process optimization on existing pipelines.
