Electric Brass Hot Runner Spring Coil Heater Heating Element

Electric Brass Hot Runner Spring Coil Heater Heating Element
Electric Brass Hot Runner Spring Coil Heater Heating Element Electric Brass Hot Runner Spring Coil Heater Heating Element Electric Brass Hot Runner Spring Coil Heater Heating Element

Large Image :  Electric Brass Hot Runner Spring Coil Heater Heating Element

Product Details:
Place of Origin: China
Brand Name: GME
Certification: CE
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs
Packaging Details: cartons， pallet
Delivery Time: 7~10 working days
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 100000 pcs per Month
Contact Now
Detailed Product Description
Power Source: Electric Dimension: Customized
Voltage: 110-240V / 50-60Hz Warranty: One Year
Power: 195W-690W Style: Straight Or Coil
Heating Wire Material:: Cr20Ni80 Coiling Scheme: Tangential, Radial Exits, Axial
Material: Brass Or Stainless Steel Color: Copper
Application: Widely Used Height: 10mm~200mm
Highlight:

Electric Spring Coil Heater

Electric Brass Hot Runner Spring Coil Heater Heating Element

Description:

hot runner coil heater according with different sizes (the sprue bush or nozzle) design and manufacturing, the sleeve is made of high quality stainless steel or copper, inner sleeve, outer there are various winding section (round, square or flat) heating coil, temperature uniformity, thermal inertia characteristics, can be integrated with the K type, J type or E type control temperature thermocouple







Specification:





Minimum diameter Φ

10mm

Voltage

12V- 400V

Wattage tolerance

±10%

Material

SS304/SS321/SS310/SS316 (Customized)

Sleeve material

Brass

Resistance

±10%

Dielectric strength

600V 800V 1000V

Insulation(cold 1000V)

>10 MΩ

Leakage current(cold)

<0.5mA

Max power density

10W/cm²

Heating length tolerance

±0.05mm

Maximum working temperature allowed on sheath

Max.750℃ / 1380°F

Build-in Thermocouple

Type K/ J/ E

Standard supply 1000mm PTEE insulated nickel lead wire

Material of lead wire:Fiberglass, Kevlar, Telfon, Silicone Rubber, Metal braided, SUS armoured.


Application:



1.Injection molding machine nozzle
2. Hot Runner Nozzles & Bushings
3. Packaging machinery
4. Hot runner Injection Molds

5. Injection & Blow Moulding Machine Nozzles
6. PET preform & Thin wall container Moulds
7. Hot runner Manifolds

Electric Brass Hot Runner Spring Coil Heater Heating Element 0



Tag:

electric resistance heater,

Electric Coil Heaters,

coil heater with thermocouple
