Electric Spring Hot Runner Coil Heater With Thermocouple

Large Image : Electric Spring Hot Runner Coil Heater With Thermocouple

Product Details:

Place of Origin:	China
Brand Name:	GME
Certification:	CE

Payment & Shipping Terms:

Minimum Order Quantity:	50pcs
Packaging Details:	cartons， pallet
Delivery Time:	7~10 working days
Payment Terms:	T/T, Western Union, MoneyGram, L/C
Supply Ability:	100000 pcs per Month

Contact Now

Detailed Product Description

Power Source:	Electric	Dimension:	Customized
Voltage:	12-480V	Sheath Material:	Stainless Steel Or Nickel
Cross Section:	3.2*1.8mm	Style:	Straight Or Coil
Lead Wire:	Copper, , Fiberglass Silicon	Coiling Scheme:	Tangential, Radial Exits, Axial
Highlight:	Electric Spring Hot Runner Coil Heater , Thermocouple Coil Heater , 480V Coil Heater With Thermocouple

Electric spring hot runner coil heater with thermocouple

Description:

1) Hot runner heater is the important component of hot runner system, which is made of special technque and high quality material, ensuring its efficient work in the close space, even when the heating jacket temperature is 700 degrees Celsius. Complying with the metric system and the international standard, all models are on the basis of our quality inspection requirements, so as to meet most factories and hot runner machines.

2) we provide several kinds of heaters, such as pipe heater, press in brass heater, coil heater and so on.

Specification:

When you order ,pls provide this information

D: Inner Diameter (mm) 2. C: Height(mm)
Section Area: E*F(mm)
A: Lead Wire

5. Q:Quantity

Sheath Material	Cr Ni-Steel
Insulation Material	MgO
Resistance Wire	Ni Cr 80-20
Maximum Sheath Temperature	700°C
Die Electrical Strength	800V A/C
Insulation	> 5 M W
Thermocouple	J type (Standard) or K type
Length Tolerance (Straight)	5%
Wattage Tolerance	+ 10% (+ 5% Available Upon Request)
Resistance Tolerance	+ 10% (+ 5% Available Upon Request)
Unheated Length	35mm (Standard)
Dimensional Tolerance	Coil I.D + 0.1 to 0.2mm
Dimensional Tolerance	Coil Length + 1mm

Electric Spring Hot Runner Coil Heater With Thermocouple 0

Application:

1. Injection moulding machine nozzle

2. Hot Runner Nozzles & Bushings.

3. Packaging machineries

4. Hot runner Injection moulds.

5. Injection & Blow Moulding Machine Nozzles.

6. PET prefrom & Thin wall container Moulds

7. Hot runner Manifolds.
