1500W MgO Insulation Coil Heater For Injection Nozzle Heating

1500W MgO Insulation Coil Heater For Injection Nozzle Heating

    • 1500W MgO Insulation Coil Heater For Injection Nozzle Heating
    • 1500W MgO Insulation Coil Heater For Injection Nozzle Heating
    • 1500W MgO Insulation Coil Heater For Injection Nozzle Heating
  • 1500W MgO Insulation Coil Heater For Injection Nozzle Heating

    Product Details:

    Place of Origin: China
    Brand Name: GME

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 pcs
    Packaging Details: Standard exporting package
    Delivery Time: 10-15 days
    Payment Terms: L/C, Western Union, T/T, Paypal
    Supply Ability: 20,000 pcs per month
    Contact Now
    Detailed Product Description
    Sheath Material: Stainless Steel Heating Wire: Nichrome
    Insulation Material: MgO Outline: Flat, Round, Square Shape
    Cross Section: 2.2 X 4.2mm, 3.2 X 1.8mm, 3x3mm, Dia 1.8mm, Etc Heating Length: 250-2500mm, Customized
    Unheating Length: 35-50mm, Or Customized Lead Wire Sheath: Fiberglass Or Steel Mesh, Customized
    Exits: Axial, Tangential, Radial, Special Exits Built-in Thermocouple: J Or K
    High Light:

    1500W Coil Heater

    ,

    Coil Heater With MgO Insulation

    ,

    MgO Insulation Injection Nozzle Heater

    Coil Heater Spiral Resistor In Straight Line 1500W For Injection Nozzel Heating





    1. Introduction



    Hot runner heater is an advance concept of thermal engineering which has a construction similar to high watt density cartridge heaters.
    Hot runner heater are also known as high performance tubular heaters or cable heaters. The basic construction of these heaters consist of compacted MgO, high temperature resistance wire and Chrome Nickel Steel tube.
    Hot runner heater can be constructed with or without built in thermocouples. They are usually installed where space available for heating is limited and are widely used on hot runner nozzles, and manifolds, die cast nozzles, packaging machines etc
    All coil heaters are available with various exits and connections to suit the respective application.





    2. Features



    Standard sizes available with various cross section
    Various Watt Density options available.
    Robust Design with Choice of Terminal Exits
    Available with built in Thermocouple
    Designed for even heat profile.
    Precision fit on Hot Runner Nozzles & Manifolds.
    Highly Non-corrosive.
    Maximum heat transfer due to more contact area.
    Advanced Thermal Engineering.





    3. Coil exits


    1500W MgO Insulation Coil Heater For Injection Nozzle Heating



    4. Application



    - Hot runner system

    - Plastic industry

    - Packaging machinery

    - Medical equipment

    - Foundry technology

    - Numerous other thermal processes





    5. Order, please advise


    - Dimension
    - Wattage and voltage
    - With/wtithout J or K thermocouple
    - Heated length
    - Other your additional details
