Tubular Spiral 110V 220V Water Coil Heater With SUS304 Sheath

Tubular Spiral 110V 220V Water Coil Heater With SUS304 Sheath

    • Tubular Spiral 110V 220V Water Coil Heater With SUS304 Sheath
    • Tubular Spiral 110V 220V Water Coil Heater With SUS304 Sheath
    • Tubular Spiral 110V 220V Water Coil Heater With SUS304 Sheath
    • Tubular Spiral 110V 220V Water Coil Heater With SUS304 Sheath
  • Tubular Spiral 110V 220V Water Coil Heater With SUS304 Sheath

    Product Details:

    Place of Origin: China
    Brand Name: GME
    Certification: CE

    Payment & Shipping Terms:

    Minimum Order Quantity: 50pcs
    Price: Negotiable
    Packaging Details: cartons, pallet
    Delivery Time: 7~10 working days
    Payment Terms: T/T, Western Union, MoneyGram, L/C
    Supply Ability: 100000 pcs per Month
    Contact Now
    Detailed Product Description
    Power Source: Electric Dimension: Customized
    Voltage: 120v 220v 240v 380v, 220V Sheath Material: Stainless Steel Or Nickel
    Cross Section: 3.0x3.0,3.3x3.3mm,4.50 * 4.50 Mm Style: Straight Or Coil
    Lead Wire: , Fiberglass , Metal Mesh Coiling Scheme: Tangential, Radial Exits, Axial
    Material: Brass And Stainless Steel Application: Manifolds, Hot Runner/ Injection
    Surface Finishing: Bright Or Soft Annealed Insulation Resistance: > 5 MΩ
    Type: Injection Mold Heater
    High Light:

    Tubular Spiral Water Coil Heater

    ,

    220V Water Coil Heater

    ,

    sus304 sheath electric coil heaters

    custom tubular spiral heater elements 110v220v water coil heater

    Description:



    1) Stainless steel tubular heater is cylindrical electrical heating elements with two head. Protected with a stainless steel sheath. Mostly double head heater is used for heating up solids such as injection presses heating plates or various tools, double head heater can also be used for heating up water of gases under certain conditions.The choice of technology will depend on technical specifications required and the application.When you don't know exactly which product you are looking for, we will recommend you the best solution for your needs.



    2) Tubular heaters are custom designed in a various shapes to as client’s requirements for direct immersion in liquids such as water, oils, solvents and process solutions, molten materials as well as air and gases.


    Specification:



    Tubular heaters are produced using Incoloy, stainless steel or Copper sheath materials and also there is huge variety of selection of termination styles available. Insulation of Magnesium offers greater heat transfer. Tubular heaters can be used in any application. Straight tubular can be inserted in machined groves for conductive heat transfer and formed Tubular provides consistent heat in any type of special application. Its applications areas are: Plastic processing machineries ;Engineering Industry ;Packaging machinery ;Shoe making machineries ;Foundry Equipment ;Radiant Surface heating ;Hot Runner Mould Systems etc.



    It may be used to heat any kind of substance or material, such as oil, air, or sugar. However, a common application is plastic pellets, which are melted in order to form molded plastic parts. An example of such a process is the "hot runner" process. Electric Tubular Heater resemble tubular heaters structurally but tend to have higher watt densities.



    Wattage Tolerance
    +5%, -10%
    Resistance tolerance
    +10%, -5%
    Insulation resistance (cold)
    ≥ 500 MΩ
    Maximum leakage current (cold)
    ≤ 0.5 mA
    Dielectric strength
    1500 V
    Packaging
    Plastic bag , Carton box, Wooden box
    Sheath/Casing materials
    SUS304/ SUS321/ SUS316/ SUS316L/ SUS310S/ Incoloy800/ Incoloy840/ Copper/ Titanium
    Terminal Styles
    Plain Pins/ Flag Terminals/ Spade Terminal/ Screw Terminal/ Special Terminal
    Shape
    U/ Hairpin/ W/ Z/ Straight/ Spiral/ Circular(with extension)/ Double Loop/ Bent Hairpin
    End cap
    Ceramic end (standard)/ Cement/ Epoxy/ RTV seal
    Construction Type
    Swaged / High Watt Density – up to 1400°F (760°C)
    Not Swaged / Low Watt Density – up to 1200°F (650°C)
    Other



    Tubular Spiral 110V 220V Water Coil Heater With SUS304 Sheath
