Wuhan Global Metal Engineering Co., Ltd
The pioneer manufacturer of heaters & sensors
 |
| Place of Origin: | China |
| Brand Name: | GME |
| Certification: | CE |
| Minimum Order Quantity: | 50pcs |
|---|---|
| Packaging Details: | cartons， pallet |
| Delivery Time: | 7~10 working days |
| Payment Terms: | T/T, Western Union, MoneyGram, L/C |
| Supply Ability: | 100000 pcs per Month |
| Power Source: | Electric | Temperature Range: | -200~650℃ |
|---|---|---|---|
| Voltage: | 12-480V | Probe Material: | SS304/SS316 |
| Style: | K, J, S | Pairs Quantity Of Element: | Simplex/duplex |
| Heating Element: | Nichrome Resistance | Mounting: | Thread/flange/none |
| Function: | Temperature Sensor | Feature: | Economical |
| Types Of Terminal Box: | Anti-spray/water-proof | Connection: | Thread |
| Sample: | Available | ||
| High Light: | Thread K Type Thermocouple,Gas Turbine Exhaust K Type Thermocouple,CE k style thermocouple |
||
Customized Professional Good Price of Thermocouple K-type with Quality Assurance
Description:
Thermocouple is a temperature sensing element, it can be directly perceived level of transformation temperatures. Twoends ofconductor with different materials is weldingtogether to form a closed loop, when there is a temperature difference between the two ends, it will generate thermoelectric power in the loop. Thisphenomenon is known as the thermoelectric effect.
Specification:
| Type | Positive and negative pole materials | Model | Range | Wire diameter | Accuracy | Allowable difference |
| K | Nickel chromium nickel silicon | WRK (WRN) | -200~1260C | 0.3~3.2 | I | ±1.5°C or ±0.4%t |
| N | Nickel chromium silicon nickel silicon magnesium | WRN (WRM) | -200~1300C | 0.3~3.2 | I | ±1.5°C or ±0.4%t |
| E | Nickel chrome Copper nickel | WRE | -200~900C | 0.3~3.2 | I | ±1.5°C or ±0.4%t |
| J | Iron copper nickel | WRJ (WRF) | -40~750C | 0.3~3.2 | I | ±1.5°C or ±0.4%t |
| T | Copper copper nickel | WRT (WRC) | -200~350C | 0.2~1.6 | I | ±0.5°C or ±0.4%t |
| S | Platinum and rhodium10 Platinum | WRS (WRP) | 0~1600C | 0.5 | I | ±1°C or ±[1+0.3%(t-1100)]°C |
| R | Platinum and rhodium13 Platinum | WRR (WRQ) | 0~1600C | 0.5 | I | ±1°C or ±[1+0.3%(t-1100)]°C |
| B | Platinum and rhodium30 Platinum and rhodium6 | WRB (WRR) | 0~1700C | 0.5 | Ⅱ | ±0.25%t |
| C | Tungsten rhenium5 Tungsten rhenium26 | WRC (WRW) | 0~2300C | 0.5 | Ⅱ | ±4°C or 1.0%|t| |
| D | Tungsten rhenium3 Tungsten rhenium25 | WRD (WRW) | 0~2300C | 0.5 | Ⅱ | ±4°C or 1.0%|t| |
Application:
Thermocouples are widely used in science and industry; applications include temperature measurement for kilns, gas turbine exhaust, diesel engines, and other industrial processes. Thermocouples are also used in homes, offices and businesses as the temperature sensors in thermostats, and also as flame sensors in safety devices for gas-powered major appliances.
