| Place of Origin: | China |
| Brand Name: | GME |
| Certification: | CE |
| Minimum Order Quantity: | 50pcs |
|---|---|
| Packaging Details: | cartons， pallet |
| Delivery Time: | 7~10 working days |
| Payment Terms: | T/T, Western Union, MoneyGram, L/C |
| Supply Ability: | 100000 pcs per Month |
| Power Source: | Electric | Temperature Range: | -200~650℃ |
|---|---|---|---|
| Voltage: | 12-480V | Probe Material: | SS304/SS316 |
| Style: | K, J, S | Pairs Quantity Of Element: | Simplex/duplex |
| Heating Element: | Nichrome Resistance | Mounting: | Thread/flange/none |
| Function: | Temperature Sensor | Feature: | Economical |
| Types Of Terminal Box: | Anti-spray/water-proof | Connection: | Thread |
| Sample: | Available | ||
| High Light: | temperature sensor rtd,temperature sensor rtd pt100 |
||
Armored K Type Thermocouple Rtd Temperature Sensor For Electric Stove
Description:
1) The product is assured to be used in various conditions since its thermowell could not only resist corrsion but also with certain mechanical strength. Assembly RTD temperature sensors are widley applied to aviation, nuclear energy, petrochemical, metallurgy, machinery, electric power industries and technical area, especially suitable for narrow and curved installation space or applications that is micromation or fast response is required.
2) Armored Thermocouple Sensor is a temperature measuring device consisting of two dissimilar conductors that contact each other at one or more spots. It produces a voltage when the temperature of one of the spots differs from the reference temperature at other parts of the circuit
3) Armored Thermocouple Sensor is a widely used type of temperature measurement and control, and can also convert a temperature gradient into electricity. Commercial thermocouples are inexpensive, interchangeable, are supplied with standard connectors, and can measure a wide range of temperatures.
Specification:
■ Fast response: smaller the product diameter is, faster the temperature will be changed;
■ Product with good mechanic strength and air tightness, could be applied under harsh conditions including vibration, low and high operating temperature;
■ With high accuracy, large range (-200℃~+1300℃, could be made with -270℃~2800℃ for special conditions) and long service life;
|
Item Name
|
Armored Temperature S/T/E/R/J K Type Thermocuple Sensor for Various Temperature
|
|
Element
|
Single element, thermocouple, 2 wire
|
|
Accuracy
|
Class I, Class II
|
|
Measurement Range
|
K (-50 ~ 1300°C), S (-50 ~ 1700°C), E (0 ~ 800°C), J (0 ~ 1000°C), B (300 ~ 1800°C) etc
|
|
Probe Materia
|
304SS or customized
|
|
Probe Size
|
Φ2mm, 3mm, 5mm, 6mm, 8mm, 10mm or customized
|
|
Connecting Head
|
Cable ; Water-proof, explosion-proof, splash-proof metal case
|
|
Electrical Connection
|
Cable; water-proof, explosion-proof metal case
|
|
Connecting Cable
|
Normal cable, PVC; PTFE, High temperature proof cable, silica gel cable, Mica cable etc
|
Application:
● Plastic injection molding machinery
● Food processing equipment
● Engine and turbine exhaust gas
● Semiconductor processing
● Heat treating and metals processing
● Medical equipment
● Aerospace industries
● Packaging equipment
● Test stands
