Wuhan Global Metal Engineering Co., Ltd
The pioneer manufacturer of heaters & sensors
 |
| Place of Origin: | China |
| Brand Name: | GME |
| Certification: | CE |
| Minimum Order Quantity: | 50pcs |
|---|---|
| Packaging Details: | cartons， pallet |
| Delivery Time: | 7~10 working days |
| Payment Terms: | T/T, Western Union, MoneyGram, L/C |
| Supply Ability: | 100000 pcs per Month |
| Power Source: | Electric | Temperature Range: | -200~650℃ |
|---|---|---|---|
| Voltage: | 12-480V | Probe Material: | Stainless Steel Or Nickel |
| Calibratio: | K//N/E/J/T | Pairs Quantity Of Element: | Simplex/duplex |
| Heating Element: | Nichrome Resistance | Mounting: | Thread/flange/none |
| Function: | Temperature Sensor | Feature: | Economical |
| Types Of Terminal Box: | Anti-spray/water-proof | Connection: | Thread |
| Diameter: | 0.5mm | ||
| Highlight: | temperature sensor rtd,temperature sensor rtd pt100 |
||
Industrial MgO Mineral Insulated Cable MI Cable with stainless steel 321, 310, 316 sheath
Description:
1) The sheath cable are small outer diameter, quick heat responsive period, can be bent , long service life, fine air-tight, wide temperature measure range, high voltage resistant, anti-vibration, narrow mounting pipeline and can be used on bending condition
2) M.I. (Mineral Insulated) cable is used to insulate thermocouple wires from one another and from the metal sheath that surrounds them. MI Cable has two (or four when duplex) thermocouple wires running down the middle of the tube. The tube is then filled with magnesium oxide powder and compacted to ensure the wires are properly insulated and separated. MI cable helps to protect the thermocouple wire from corrosion and electrical interference
Specification:
1.Diameter : 3.0mm (CUSTOMIZED)
2.Model :K, E , T , J.
3.Type:Simplex
4.Material:SS310,INCONEL600,321,316L
5.Class of accuracy: I, II
6.Purity of MgO: ≥99.5%
Mineral Insulated Thermocouple Cable:
1. metal sheathed inert magnesium-oxide insulated thermocouple cable.
2. used to fabricate thermocouple probes and high temperature thermocouple extension wire.
3. can be welded, brazed, bent, coiled or formed.
4. Durable and withstands vibration under high temperatures and pressures.
| Item Name: | MI cable |
| Insulator: | Magnesium Oxide |
| sensor wires type: | Single or double |
| Sheathed Material Diameter : | 0.5,1,2,3,4,5,6,8,12 |
| Use: | Thermocouple or RTD |
| Bare material: | Pt,Rh,Ni,Cr,Si,Cu,Fe |
| Response time: | 3sec to10sec/Variable depend upon types |
| Temperature range: |
-200 t0 600(RTD),-40 to1700(Thermocouple)
|
| Outer Material: | 304,321,310,316,INconel600,GH3030 |
| Certification: | ISO9001, ISO14001 |
| Package: | carton box or as your requirement |
