| Place of Origin: | China |
| Brand Name: | GME |
| Certification: | CE |
| Minimum Order Quantity: | 50pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | cartons， pallet |
| Delivery Time: | 7~10 working days |
| Payment Terms: | T/T, Western Union, MoneyGram, L/C |
| Supply Ability: | 100000 pcs per Month |
| Power Source: | Electric | Dimension: | Customized |
|---|---|---|---|
| Voltage: | 380V, 600w | Sheath Material: | Stainless Steel Or Nickel |
| Cross Section: | 2.2*4.2mm | Style: | Straight Or Coil |
| Lead Wire: | Copper, , Fiberglass Silicon | Coiling Scheme: | Tangential, Radial Exits, Axial |
| Material: | Brass And Stainless Steel | Application: | Manifolds Hot Runner Injection |
| Thermocouple: | With Or Without Type J Or K | ||
| High Light: | electric resistance heater,coil heater with thermocouple |
||
220v 240w coil heater spring heater hot runner for plastic injection moulds
Description:
1) Length of Hot runner heater with in 20-3000mm is mainly used for hot runner mold or, as well as other precision heating system.
2) Spring heating ring external using high quality Ni-Cr steel tube, the internal use of high purity magnesium oxide , high temperature resistance wire, and first-class manufacturing technology
3) It has a simple structure, but it is more various in usage;
4)) It can be bended to any shapes, fastened to the machine or electric heating implementdirectly, or inserted into mold or hole in the heating board, in this situation, the heater can getexact and high efficient heat source, eliminate the lost of heat and make sure the heat would beadopted by the mold or heat board, then it can reach the goal of saving energy;
5) It has the advantages of high thermal efficiency, good mechanical strength, safe, realiable,sentivite advantages;
.
Specification:
Unique design to ensure temperature control accuracy,even heating,heat insulating,low power consumption and long life time.
1.Wattage & voltage:Per customers' requirement.
2.Application: Hot Runner System,Plastic Injection Machine,Plastic Extruding Machine,etc.
3.TC:K/J/E(optional)
4.Warranty:12months
| Name of product | Spring coil hot runner heater |
| Inner Diameter of coiled heater | 8-100mm(+0.05mm) |
| Coil style Length | 15-400mm(+0.05mm) |
| Staright style length | 400-3000mm(0.5mm) |
| Cross-section |
Round Dia:1.8mm;3.7mm;4.2mm Square:3.2×3.2mm;3.6×3.6mm; Rectangular:1.5×2.1mm;2.2×4.2mm;2.3×4.3;4×6mm; |
| Tube Material | SUS316 |
| Power | According to your requirement |
| Insulation | High purity MGO |
| Inner heating element | NiCi8020 |
| Voltage | 110v;220v;240v;380v |
| Wattage | 100-1500W(5w/cm2) +5% -10% |
| Max temperature | 650℃ |
| Built-in thermocouple | With or without J/K TC(Available) |
| Service | ODM/OEM |
| Delivery time |
3-5 days (10-500pcs) 7days(More than 500pcs) |
