Wuhan Global Metal Engineering Co., Ltd
The pioneer manufacturer of heaters & sensors
 |
| Place of Origin: | China |
| Brand Name: | GME |
| Certification: | CE |
| Minimum Order Quantity: | 50pcs |
|---|---|
| Packaging Details: | cartons， pallet |
| Delivery Time: | 7~10 working days |
| Payment Terms: | T/T, Western Union, MoneyGram, L/C |
| Supply Ability: | 100000 pcs per Month |
| Power Source: | Electric | Dimension: | Customized |
|---|---|---|---|
| Voltage: | 380V, 240V | Sheath Material: | Stainless Steel Or Nickel |
| Cross Section: | 3.0x3.0,3.3x3.3,4.50 * 4.50 Mm | Style: | Straight Or Coil |
| Lead Wire: | , Fiberglass , Metal Mesh | Coiling Scheme: | Tangential, Radial Exits, Axial |
| Material: | Brass And Stainless Steel | Application: | Manifolds Hot Runner Injection |
| High Light: | electric resistance heater,Electric Coil Heaters |
||
Industry High Temperature Hot Runner Coil Heater for hot runner system
Description:
1) Spiral Hot Runner Coil Heater features continuous operating temperatures up to 1200°F. Rapid heating and cooling occur, due to the low mass construction.
2) All heating elements are sealed from contamination and the stainless steel sheath provides maximum corrosion resistance.
3)An optional internal thermocouple may be utilized for precise control. Its high working temperature, fast heating, uniform heating precision, long service life, can be automatically controlled area, high thermal conduction, while internal heating material damage, external can be reuses.
.
Specification:
Standard square cable: .......................................0.125" square
Standard rectangle cable: ...................................0.080" x 0.140", 0.105" x 0.150"
Standard round cable diameters: ......................0.093", 0.125", 0.150", 0.188", 0.200", 0.250", 0.312", 0.375" - Other dimensions available
Cable diameter tolerance: ...................................±0.005
Standard potting adapter: ....................................0.281" / 0.250" diameter - used with heater only and heater with thermocouple leads, 20 gauge and finer - 1/2" - used with heater only and heater with thermocouple leads, 18 gauge to 12 gauge
Standard potting adapter length: .......................1.0" - Other lengths available
Standard coil I.D.: .................................................From 3/8" up to 2 1/2" in any increments
Coil I.D. tolerances: .............................................3/8” to3/4”, + 0.000”, - 0.020” - 7/8” to 1 1/4”, + 0.000”, - 0.030" - 1 1/2” to 2 1/2”, + 0.000”, - 0.060”
Coil length: ............................................................Up to 12” on 3/8” to 3/4” I.D. - Up to 16” on 7/8” to 1 1/4” I.D. - Up to 18” on 1 1/2” to 2 1/2” I.D.
Coil length tolerance: ...........................................0 to 6”: + 0, - 1/8” - 6 to 12”: + 1/8”, - 1/4” - 12 to 18”: ± 1/4"
| Square | 3.0*3.0,3.3*3.3,4.5*4.5mm |
| Rectangle | 4.2*2.2,4.5*2.5,3.2*1.8,1.3*2.3mm |
| Round | 3.3,1.8,1.6mm |
Application:
Blow Molding
Custom Die Applications
Extrusion
Hot Runner Systems
Injection Molding
Thermoforming
