Injection Moulding Machine Spring Enail Hot Runner Coil Heaters With Thermocouple J

Injection Moulding Machine Spring Enail Hot Runner Coil Heaters With Thermocouple J

    • Injection Moulding Machine Spring Enail Hot Runner Coil Heaters With Thermocouple J
    • Injection Moulding Machine Spring Enail Hot Runner Coil Heaters With Thermocouple J
    • Injection Moulding Machine Spring Enail Hot Runner Coil Heaters With Thermocouple J
  • Injection Moulding Machine Spring Enail Hot Runner Coil Heaters With Thermocouple J

    Product Details:

    Place of Origin: China
    Brand Name: GME
    Certification: CE

    Payment & Shipping Terms:

    Minimum Order Quantity: 50pcs
    Packaging Details: cartons, pallet
    Delivery Time: 7~10 working days
    Payment Terms: T/T, Western Union, MoneyGram, L/C
    Supply Ability: 100000 pcs per Month
    Contact Now
    Detailed Product Description
    Power Source: Electric Dimension: Customized
    Voltage: 380V, 600w Sheath Material: Stainless Steel Or Nickel
    Cross Section: 3.5x3.5,3.0x3.0,3.3x3.3 Style: Straight Or Coil
    Lead Wire: 1000-3000mm Coiling Scheme: Tangential, Radial Exits, Axial
    Material: Brass And Stainless Steel Application: Manifolds Hot Runner Injection
    Highlight:

    electric resistance heater

    ,

    Electric Coil Heaters

    Injection moulding machine Spring enail hot runner coil heater with thermocouple J



    Description:


    1) Coil spring heaters are made of nickel chrome resistance wire placed inside chrome nickel steel tube filled with MgO powder and compacted for faster and efficient heat transfer

    2) The hot runner heaters are annealed to acquire malleability for bending into any shape. Injection molding coil heaters with thermocouple are also available.



    3) Our Hot Runner Coil Heater is annealed to acquire malleability for bending into any shape. Hot Runner Bushes are produced with hot runner heaters of different cross sections with inner brass and outer stainless steel cover.



    Specification:



    1.Spring ring heating specification:heating section:2.2×4.2 3×3 3.4×3.4 3.5×3.5 5.4×4mm

    2.Heating coil ID 10mm-38mm.heating height of ring:40mm-200mm

    3.Voltage:220V-380V,wattages:200W-3000W

    4.Built-in thermocouple power: with or without J/K thermocouple,length of lead wire as 500mm 1000mm 1200mm 1500mm or 2000mm

    5.Continuous Operating Temperatures to 1200℉

    Intermittent Operating Temperature to 1500℉

    6.Spring heating ring advantages:high working temperature,fast heating,long service life,convenient installation.



    Sheath of coil heater
    SUS304
    Insulation of coil heater
    Compacted magnesium Oxide
    Heating conductor
    NiCr8020
    Thermocouple
    K type, J type (optional)
    Leads
    Stainless steel braided wire, PTFE wire, glass fiber wire ( On demand)
    Voltage
    24V to 415V
    Temperature resistance
    Max 800 cent degree



    Injection Moulding Machine Spring Enail Hot Runner Coil Heaters With Thermocouple J





    Application:



    1. Injection moulding machine nozzle
    2. Hot Runner Nozzles & Bushings
    3. Packaging machineries
    4. Hot runner Injection moulds.
    5. Injection & Blow Moulding Machine Nozzles.
    6. PET prefrom & Thin wall container Moulds
    7. Hot runner Manifolds.
