Yellow High Temperature Cable High Voltage Insulated Resistance Heating Wire

Yellow High Temperature Cable High Voltage Insulated Resistance Heating Wire

    • Yellow High Temperature Cable High Voltage Insulated Resistance Heating Wire
    • Yellow High Temperature Cable High Voltage Insulated Resistance Heating Wire
    • Yellow High Temperature Cable High Voltage Insulated Resistance Heating Wire
  • Yellow High Temperature Cable High Voltage Insulated Resistance Heating Wire

    Product Details:

    Place of Origin: China
    Brand Name: GME
    Certification: CE & ISO
    Model Number: High Temperature Cable

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000 m
    Price: Negotiation
    Packaging Details: Exported Case Packing
    Delivery Time: 15-20 working days after received your payment
    Payment Terms: T/T, Western Union, D/P, L/C, Paypla
    Supply Ability: 100,000m per month
    Contact Now
    Detailed Product Description
    Product Name: High Temperature Insulated Wire Application: Electric Heater
    Conductor Type: Stranded Insulated Materials: Silicon & Mica
    Package: In Roll Or Spool Conductors: Nickel Copper, Nickel
    Color: Red/Black/Blue/Yellow Size: 26AWG~4/0 AWG

    High Temperature Insulated Wire



    1. High Temperature Cable Brief Introduction



    This cable is widely used in the wiring of heating elements, such as cartrige heater, band heater, and

    hot plates, etc. The insulation materials can be silicon and mica.



    2. High Temperature Cable Characteristics



    •  High temperature resistance,low temperature resistance
    • Anti-acid and alkali,fire and aging resistance,
    • The inoxidizability, resistance of humidity,
    • The fine electric insulation and flexible performance



    3. High Temperature Cable Parameter.





    Conductor

    Insulation

    Diameter
    FEP/S.R
    (Ω/KM)

    Unit length
    (M)(Ft)

    Size
    (AWG)

    Construction
    (No./mm)

    Diameter
    (mm)

    Mica
    Thickness
    (mm)

    Glass
    Thickness
    (mm)

    26

    7/0.16

    0.48

    ≥0.635

    0.181

    ≥2.15

    305

    24

    7/0.20

    0.61

    ≥0.635

    0.181

    ≥2.25

    305

    22

    7/0.25

    0.77

    ≥0.635

    0.181

    ≥2.40

    305

    20

    7/0.31

    0.94

    ≥0.635

    0.181

    ≥2.60

    305

    18

    16/0.254

    1.19

    ≥0.635

    0.181

    ≥2.85

    305

    16

    26/0.254

    1.49

    ≥0.635

    0.181

    ≥3.15

    305

    14

    41/0.254

    1.87

    ≥0.635

    0.181

    ≥3.50

    200

    12

    65/0.254

    2.36

    ≥0.762

    0.381

    ≥4.65

    100

    10

    35/0.45

    3.06

    ≥0.762

    0.381

    ≥5.35

    100

    8

    67/0.40

    3.75

    ≥0.762

    0.381

    ≥6.05

    100

    6

    266/0.254

    4.75

    ≥0.762

    0.381

    ≥7.05

    100

    4

    420/0.254

    6.02

    ≥0.762

    0.381

    ≥8.25

    100




    4. Application



    Apply to household appliance,Illumination & lighting & headlamp,electric machines,temperature sensor,Military series,metallurgy chemical series,motor cars & ships,electrical installation.



    Yellow High Temperature Cable High Voltage Insulated Resistance Heating Wire
