4" Industrial K Type Armoured Thermocouple RTD Sensor With Thread Connection

4" Industrial K Type Armoured Thermocouple RTD Sensor With Thread Connection

    • 4" Industrial K Type Armoured Thermocouple RTD Sensor With Thread Connection
    • 4" Industrial K Type Armoured Thermocouple RTD Sensor With Thread Connection
    • 4" Industrial K Type Armoured Thermocouple RTD Sensor With Thread Connection
    • 4" Industrial K Type Armoured Thermocouple RTD Sensor With Thread Connection
    • 4" Industrial K Type Armoured Thermocouple RTD Sensor With Thread Connection
  • 4" Industrial K Type Armoured Thermocouple RTD Sensor With Thread Connection

    Product Details:

    Place of Origin: China
    Brand Name: GME
    Certification: CE

    Payment & Shipping Terms:

    Minimum Order Quantity: 50pcs
    Packaging Details: cartons, pallet
    Delivery Time: 7~10 working days
    Payment Terms: T/T, Western Union, MoneyGram, L/C
    Supply Ability: 100000 pcs per Month
    Contact Now
    Detailed Product Description
    Power Source: Electric Temperature Range: -200~650℃
    Voltage: 12-480V Probe Material: Stainless Steel Or Nickel
    Pairs Quantity Of Element: Simplex/duplex Heating Element: Nichrome Resistance
    Mounting: Thread/flange/none Function: Temperature Sensor
    Types Of Terminal Box: Anti-spray/water-proof Connection: Thread





    4" industrial K Type armoured Thermocouple Sensor with thread connection

    Description:



    1) A thermocouple is a simple, robust and cost-effective temperature sensor used in a wide range of temperature measurement processes. It consists of two dissimilar metal wires, joined at one end. When properly configured, thermocouples can provide measurements over a wide range of temperatures.


    2) Thermocouples are Known for their versatility as temperature sensors, thermocouples are manufactured in a variety of styles, such as thermocouple probes,thermocouple probes with connectors, transition joint thermocouple probes, infrared thermocouples, bare wire thermocouple or even just thermocouple wire.



    3) Thermocouples are manufactured in many different configurations for multitude of applications. Diameters, lengths, sheath material, lead lengths and sensor material are just a few of the variables that go into determining the style of thermocouple when manufactured. The main determining factors of what type thermocouple needs to be used in a application is temperature, environment, response time and accuracy. The junction of the thermocouple can be grounded, ungrounded or exposed.


    Specification:



    1).Type: K

    2). Temperature range: 0°C-800°C

    3). Precision grade: Class A / Class B

    4). Probe diameter:8mm, can be customized

    5). Probe material: SS304/SS316

    6). Probe length:2000mm or customized

    7). Movable thread size: M27*2

    8). Thermocouple head type: water-proof



    Model Graduation mark

    temperature

    range

    Mounting& Fixing
    WRK K 0-1300°C

    1.without Fixing Device

    2.Threaded Connector

    3.Movable Flange

    4.Fixed Flange

    5.Elbow Tube Connection

    6.Threaded Cone Connection

    7.Straight Tube Connection

    8.Fixed Threaded Tube Connection

    9.Movable Threaded Tube Connection

    WRE E 0-800°C
    WRJ J 0-800°C
    WRT T -40-350°C
    WRS S 0-1600°C
    WRR R 0-1600°C
    WRB B 600-1700°C
    WRM N

    0-1200°C




    4" Industrial K Type Armoured Thermocouple RTD Sensor With Thread Connection





    Application:


    It is usually connected with display meter, recording meter and computer, etc. to directly measue temperature of liquid, vapor, gas and solid surface ranging from 0°C to 1300C during various production process.
