Outstanding Quality PVC Thermocouple Compensable Cable S Type SC SX

Outstanding Quality PVC Thermocouple Compensable Cable S Type SC SX

    • Outstanding Quality PVC Thermocouple Compensable Cable S Type SC SX
    • Outstanding Quality PVC Thermocouple Compensable Cable S Type SC SX
    • Outstanding Quality PVC Thermocouple Compensable Cable S Type SC SX
  • Outstanding Quality PVC Thermocouple Compensable Cable S Type SC SX

    Product Details:

    Place of Origin: China
    Brand Name: GME
    Certification: CE & ISO

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 M
    Price: Negotiable
    Packaging Details: Standard Export Packing
    Delivery Time: 10-20 working days after received your payment
    Payment Terms: T/T, Western Union, Paypel
    Supply Ability: 100000 m per month
    Contact Now
    Detailed Product Description
    Type: B,S,R Protection Material: PVC
    Color: Customizable Accuracy: < ± 0.5% T
    Temperature Range: 0--1800centigrade Insulation Resistance: 5MΩ (20°C)

    1. Product description:

    Place of Origin: Shanghai, China Usage: Industrial Theory: Temperature Recorder
    Accuracy: +/-1.5C Temperature range: 0--1800centigrade name: thermocouple compensable cable
    dia: 7--25mm length: 100mm-1000mm type: b s r
    packing: wooden case protection: PVC



    2. Detailed information:



    Thermocouple compensable cable for S type

    Platinum rhodium is a kind of traditional temperature measuring element.

    A thermoelectric performance stability, oxidation resistance is strong, suitable for continuous use in oxidation, the inert atmosphere.

    Long-term use of temperature of 1600 °C, short-term use temperature is 1800 °C.

    The price base on the dia of the sensor,and the quantity.

    Dia:0.1mm,0.15mm,0.25mm,0.3mm,0.35mm,0.5mm...



    3. Specification:

    Name platinum rhodium thermocouple
    Type B S R
    Temp range 0-1800 centigrade
    Accuracy < ± 0.5% t
    Insulation resistance 5MΩ (20°C)
    Size 100mm-1200(mm)



    4. Applications:

    Thermocouple compensation cable is used to connect thermocouple sensor with measuring devices, such as controller, indicator or temperature recorder. The cable is made of substitute material with properties similar to thermocouples and the insulation is selected according to ambient conditions and operating temperature.

    The thermocouple total potential value only relate to the temperature of hot end and reference junction without influence of intermediate temperature. So compensation could extend the heat to the meter terminal instead of expensive compensation wire.

    Thermocouple cable not only measurement errors but also can improve physical and mechanical properties of thermocouple line

    Multi-strand core or small diameter wire compensation can improve the flexibility of the line and make the connection convenient. Besides, It is easy to shield from outside interference and reduce the Road costs for measurement line.



    5. Delivery



    S Type 20 AWG Fiberglass Braided Thermocouple Compensation Cables
