Mineral Insulated Type K J T E Thermocouple Mi Cable

Mineral Insulated Type K J T E Thermocouple Mi Cable

    • Mineral Insulated Type K J T E Thermocouple Mi Cable
    • Mineral Insulated Type K J T E Thermocouple Mi Cable
    • Mineral Insulated Type K J T E Thermocouple Mi Cable
    • Mineral Insulated Type K J T E Thermocouple Mi Cable
  • Mineral Insulated Type K J T E Thermocouple Mi Cable

    Product Details:

    Place of Origin: China
    Brand Name: GME
    Certification: CE

    Payment & Shipping Terms:

    Minimum Order Quantity: 50pcs
    Packaging Details: cartons, pallet
    Delivery Time: 7~10 working days
    Payment Terms: T/T, Western Union, MoneyGram, L/C
    Supply Ability: 100000 pcs per Month
    Contact Now
    Detailed Product Description
    Power Source: Electric Temperature Range: -200~650℃
    Voltage: 12-480V Probe Material: Stainless Steel Or Nickel
    Style: PT100, PT1000, PT500, K, J Pairs Quantity Of Element: Simplex/duplex
    Heating Element: Nichrome Resistance Probe Length: 30-1000mm
    Usage: Temperature Sensor Temperature: 0-800C
    Types Of Terminal Box: Anti-spray/water-proof
    High Light:

    Type E Thermocouple Mi Cable

    ,

    Type T Thermocouple Mi Cable

    ,

    type j thermocouple mineral insulated cables

    Mineral insulated cable type k,j,t,e thermocouple mi cable



    Description:

    There are multiple types and grades of thermocouple wire.Each type of thermocouple wire has a specific combination of metal alloys.This combination is what defines the type of thermocouple.Thermocouple grade wire is used to manufacture thermocouple probes.Thermocouple grade wire is normally used for the junction and inside the stem sheath.

    Code
    +Positive leg
    -Negative leg
    N
    Ni-Cr-Si(NP)
    Ni-Si-Mg(NN)
    K
    Ni-Cr-Si(KP)
    Ni-Al(KN)
    E
    Ni-Cr(EP)
    Cu-Ni<constantan>(EN)
    J
    Iron(JP)
    Cu-Ni<constantan>(JN)
    T
    Copper(TP)
    Cu-Ni<constantan>(TN)
    B
    Platinum Rhodium-30%
    Platinum Rhodium-6%
    R
    Platinum Rhodium-13%
    Platinum
    S
    Platinum Rhodium-10%
    Platinum



    Features



    Mineral Insulated Thermocouple Cable

    Temperature range:-200-1300

    MI cable: OD 0.25 - 8.00
    Sheath material: Inconel 600, SS316, SS304, SS321.
    Mini coil length: Per client's request
    Accuracy: Class I, II
    Wire: Simplex & duplex



    Electric property:

    Resistance value allowance:±10%

    Dielectric property:heating cable pressure resist:1200V AC/1min

    Insulation resistance:end product test:100MΩ/500VDC

    Sheath continuity:all the heating cable submerged in the water 12 hours then test the insulation resistance,the value should be 50M/500VDC at least.



    Mineral Insulated Type K J T E Thermocouple Mi Cable
