Hot Runner Brass Tube Electric Coil Heaters with Thermocouple

Hot Runner Brass Tube Electric Coil Heaters with Thermocouple

    • Hot Runner Brass Tube Electric Coil Heaters with Thermocouple
    • Hot Runner Brass Tube Electric Coil Heaters with Thermocouple
    • Hot Runner Brass Tube Electric Coil Heaters with Thermocouple
    • Hot Runner Brass Tube Electric Coil Heaters with Thermocouple
  • Hot Runner Brass Tube Electric Coil Heaters with Thermocouple

    Product Details:

    Place of Origin: China
    Brand Name: GME
    Certification: CE

    Payment & Shipping Terms:

    Minimum Order Quantity: 50pcs
    Price: Negotiable
    Packaging Details: cartons, pallet
    Delivery Time: 7~10 working days
    Payment Terms: T/T, Western Union, MoneyGram, L/C
    Supply Ability: 100000 pcs per Month
    Contact Now
    Detailed Product Description
    Power Source: Electric Dimension: Customized
    Voltage: 120v 220v 240v 380v, 220V Sheath Material: Stainless Steel Or Nickel
    Cross Section: 3.0x3.0,3.3x3.3mm,4.50 * 4.50 Mm Style: Straight Or Coil
    Lead Wire: Teflon, Fiberglass , Metal Mesh Coiling Scheme: Tangential, Radial Exits, Axial
    Material: Brass And Stainless Steel Application: Manifolds, Hot Runner/ Injection
    Color: Silver Or Fully Black

    Hot Runner Brass Tube Electric Coil Heaters with Thermocouple



    Description:



    1) Spring coil heater is made of nickel chrome resistance wire placed inside chrome nickel steel tube that is filled with MgO powder.
    Spring coil heater is also known as high performance tubular heaters or cable heaters.



    2) Spring heater can be produced with orwithout built in thermocouples. Spring coil heater is widely used in heating engineering, mold, plastic industry, including the transfer machinery, medical equipment, casting process, welding, heat treatment process and many other industries and fields.



    Specification:



    Main Features

    * Standard sizes available with various cross section

    * Various Watt Density options available.
    * Robust Design with Choice of Terminal Exits
    * Available with built in Thermocouple
    * Designed for even heat profile.
    * Precision fit on Hot Runner Nozzles & Manifolds.
    * Highly Non-corrosive.

    * Maximum heat transfer due to more contact area.
    * Advanced Thermal Engineering.



    Item name
    ID25mm e-nail coil heater for injection molding /fog machine
    Resistance heating wire
    Ni-Cr or FeCr
    Sheath
    stainless steel 304,321,316, Incoloy 800, Incoloy 840, Ti
    Insulation
    High-purity Mgo
    Maximum temperature
    700 degree Celsius
    Die Electrical Strength
    800V A/C
    Insulation
    > 5 M W
    Wattage Tolerance
    +5%, -10%
    Thermocouple
    K type or J type
    Lead wire
    300mm length; Different type of wire (Teflon/silicone high temperature frberglass) is available



    Hot Runner Brass Tube Electric Coil Heaters with Thermocouple



    Application:



    * Injection moulding machine nozzle

    * Hot Runner Nozzles & Bushings.
    * Packaging machineries
    * Hot runner Injection moulds.
    * Injection & Blow Moulding Machine Nozzles.
    * PET preform & Thin wall container Moulds
    * Hot runner Manifolds.
