Industrial Spring Stainless Steel Heating Coil Electric Hot Runner Heater

Large Image : Industrial Spring Stainless Steel Heating Coil Electric Hot Runner Heater

Product Details:

Place of Origin:	China
Brand Name:	GME
Certification:	CE

Payment & Shipping Terms:

Minimum Order Quantity:	50pcs
Price:	Negotiable
Packaging Details:	cartons， pallet
Delivery Time:	7~10 working days
Payment Terms:	T/T, Western Union, MoneyGram, L/C
Supply Ability:	100000 pcs per Month

Contact Now

Detailed Product Description

Power Source:	Electric	Dimension:	Customized
Voltage:	120v 220v 240v 380v, 220V	Sheath Material:	Stainless Steel Or Nickel
Cross Section:	3.0x3.0,3.3x3.3mm,4.50 * 4.50 Mm	Style:	Straight Or Coil
Lead Wire:	, Fiberglass , Metal Mesh	Coiling Scheme:	Tangential, Radial Exits, Axial
Material:	Brass And Stainless Steel	Application:	Manifolds, Hot Runner/ Injection
Surface Finishing:	Bright Or Soft Annealed	Insulation Resistance:	> 5 MΩ
Highlight:	electric resistance heater , coil heater with thermocouple , Coil Electric Hot Runner Heater

Industrial Spring Stainless Steel Heating Coil Electric Hot Runner Heater

Description:

1) Length of Hot runner heater within 20-3000mm is mainly used for hot runner mold or, as well as other precision heating system. Spring heating ring external using high quality Ni-Cr steel tube, the internal use of high purity magnesium oxide , high temperature resistance wire, and first-class manufacturing technology .

2) The wire is after the annealed, with flexibility can be bent into an arc or circle heating. Its high working temperature, fast heating, uniform heating precision, long service life, can be automatically controlled area, high thermal conduction, while internal heating material damage, external can be reuses.

Specification:

Technical Specifications

1. Maximum Sheath Temperature: 700°C
2. Voltage: 12V~380V
3. Wattage: 70W~1000W
4. Sectional area: 3X3,4.2X2.2,4X2,4X2.7,4X2.5 3.3 X 3.3 3.5 X 3.5 4 X 4,2.2X1.3

5. Available sheath: nylon,metal braided,fiberglass ,silicone rubber, kevlar

Sheath Material	Cr Ni-Steel
Insulation Material	MgO
Resistance Wire	Ni Cr 80-20
Maximum Sheath Temperature	700°C
Die Electrical Strength	800V A/C
Insulation	>5 M W
Thermocouple	J type (Standard) or K type
Length Tolerance (Straight)	5%
Wattage Tolerance	+/- 10% (+/- 5% Available Upon Request)
Resistance Tolerance	+/- 10% (+/- 5% Available Upon Request)
Unheated Length	35mm (Standard)
Dimensional Tolerance	Coil I.D +/- 0.1 to 0.2mm Coil Length +/- 1mm

Industrial Spring Stainless Steel Heating Coil Electric Hot Runner Heater 0

Production Flow:

1.Hot Runner & Bushings

2.Tube Extrusion

3.Pipe Forming

4.Hot Runner Mould

5.Plastic Injection Machine

6.Plastic Extruder Machine
