Industrial PT100 Thermocouple RTD , Platinum RTD Temperature Sensor High Accuracy

Industrial PT100 Thermocouple RTD , Platinum RTD Temperature Sensor High Accuracy

    • Industrial PT100 Thermocouple RTD , Platinum RTD Temperature Sensor High Accuracy
    • Industrial PT100 Thermocouple RTD , Platinum RTD Temperature Sensor High Accuracy
    • Industrial PT100 Thermocouple RTD , Platinum RTD Temperature Sensor High Accuracy
  • Industrial PT100 Thermocouple RTD , Platinum RTD Temperature Sensor High Accuracy

    Product Details:

    Place of Origin: Wuhan, China
    Certification: ISO9001/ CE

    Payment & Shipping Terms:

    Minimum Order Quantity: 10PCS
    Price: Negotiable
    Packaging Details: Normal exporting cartons
    Delivery Time: 100000 pcs per Month
    Payment Terms: L/C, T/T, Western Union
    Contact Now
    Detailed Product Description
    Usage: Industrial Application: Measuring Temperature
    Function: Measuring Temperature Temperature Range: -20-420
    Tube Material: GH3039/ss304/ss316 Certificate: BV/CE/SGS

    RTD Platinum temperature sensor PT100 PT500 PT1000

    Pt-100 RTD thermocouple pt100 temperature sensor


    Product Description

    The C series thin-film PRTDs combine the ideal curve characteristics of ceramic wire-wound RTDs with the vibration
    resistance of glass wire-wound RTDs and represent an excellent alternative to wire-wound RTDs. They are characterized
    by high long-term stability, excellent temperature shock resistance and a wide temperature range of -196°C to +150°C.
    The deviation from the DIN EN 60751 (according to IEC 751) characteristic curve is minimal over the entire temperature
    range, they show no hysteresis. These features make them best suited for applications in aerospace, chemical and power
    generation plants and analytical equipment.





    Main feature
    • Glass coated platinum element
    • Virtually linear relationship between temperature and resistance
    • Capable of withstanding temperatures ranging from -50°C to +500°C. Higher temperature ratings are available by special order
    • High accuracy: Resistance and temperature deviation can be controlled to within ±0.06% and ±0.15°C, a tolerance that corresponds to Class “A” of IEC 751 or 1/2 DIN of DIN 43760
    • High Reliability: Capable of withstanding extreme environmental conditions
    • Available in various configurations for specific applications
    • Excellent stability even at high temperatures
    • Specifications

    Industrial PT100 Thermocouple RTD , Platinum RTD Temperature Sensor High AccuracyIndustrial PT100 Thermocouple RTD , Platinum RTD Temperature Sensor High Accuracy

    Industrial PT100 Thermocouple RTD , Platinum RTD Temperature Sensor High Accuracy
