Cross switch temperature calibrator Hot Runner Temperature Controller for Industrial

Cross switch temperature calibrator Hot Runner Temperature Controller for Industrial

    • Cross switch temperature calibrator Hot Runner Temperature Controller for Industrial
    • Cross switch temperature calibrator Hot Runner Temperature Controller for Industrial
    • Cross switch temperature calibrator Hot Runner Temperature Controller for Industrial
  • Cross switch temperature calibrator Hot Runner Temperature Controller for Industrial

    Product Details:

    Place of Origin: China
    Brand Name: GME
    Certification: CE
    Model Number: 8A

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pcs
    Packaging Details: Standard Export Packing
    Delivery Time: 7-15days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 10000pcs/month
    Contact Now
    Detailed Product Description
    Usage: Industrial Theory: Temperature Controller
    Accuracy: ±0.25% Temperature Range: 0℃-500℃(32℉~932℉)
    Control Output: PWM Or SSR Output Type: Zero Cross / Phase Angle
    High Light:

    multi-zone temperature controller

    ,

    hot runner temperature controller



    Cross switch temperature calibrator Hot Runner Temperature Controller for Industrial



    Main Features


    1. Integrated construction permits easy disassembly.
    2. Adopt galvanized steel sheet. Light and handy. High capacity of anticorrosion and antirust.
    3. The card size and electric interface can be compatible with other brands such as YUDO, Athena, DME, PCS, INCOE.
    4. Adopt gold-plated card slot and machine to pressure wielding. Make sure the signals are connected reliably between box and card.
    5. The type of heavy load connections and wiring method can be custom-made.
    6. Adopt cold pressing terminals between wires and heavy load connections to make sure the signals are connected reliably.
    7. There are 2, 4, 6, 8, 10, 12, 24 zones for customers to select.



    Specifications



    Power Supply AC85~ 415V, 50/60HZ Consumed Power < 2.5W
    Control Mode Auto-PID / Manual Output Type Zero Cross / Phase Angle
    Sensor Type Thermocouple J or K Measurement Range 0~500℃(32~932℉)
    Measurement Accuracy ±0.25% FS Setting Range 0~450℃(32~842℉)
    Control Accuracy ±0.25% FS Load Capacity 20A, 50W~2200W(110V)
    100W~4400W(220V)
    Working Temperature 0~50℃(32~122℉)
    Storage Temperature -20~70℃(-4~158℉) Switching Mode Rocker Switch
    Working Humidity 10~80%RH(No condensing)



    Demension



    Type 02A 02B 04A 06A 08A 10A 12A 24A
    Zone 1 ~ 2 1 ~ 2 3 ~ 4 5 ~ 6 7 ~ 8 9 ~ 10 11 ~ 12 13 ~ 24
    Power Switch 2P-40A×1 None 3P-63A×1 3P-63A×1 3P-63A×1 3P-63A×1 3P-63A×1 3P-63A×2
    Power Supply 1-Phase 3-wire AC220V 1-Phase 3-wire AC220V 3-Phase 5-wire AC380V 3-Phase 5-wire AC380V 3-Phase 5-wire AC380V 3-Phase 5-wire AC380V 3-Phase 5-wire AC380V 3-Phase 5-wire AC380V
    Output Connector 16PIN×1 or Cable 16PIN×1 or Cable 16PIN×1 24PIN×1 16PIN×2 24PIN×2 24PIN×2 24PIN×4
    Dimension(mm) L=185 H=200 D=290 L=130 H=200 D=290 L=310 H=210 D=290 L=410 H=210 D=290 L=510 H=210 D=290 L=610 H=210 D=290 L=710 H=210 D=290 L=720 H=420 D=290





    Protection Fuctions


    1. Wide power supply range, AC85~415V
    2. Thermocouple input protection, prevent module damaged by mis-connection
    3. Thermocouple & heater inverse protection, prevent thermocouple damaged by mis-connection
    4. Soft-start mode, avoid the humidity make the heater burn out

    Diagnostic Function


    Alarm when the followings occurred
    1. Ultra-high or ultra-low Temperature
    2. Thermocouple break, short or inverse
    3. Thermocouple is out of its position
    4. Heater break, short or overload
    5. Output device is damaged

    Accessories


    Cables: provide 16/24 core combination hot runner cable and mold power cable, thermocouple cable or customized
