Stainless Steel Rigid Tubular Heater For Manifold , Diameter 8.5mm

Stainless Steel Rigid Tubular Heater For Manifold , Diameter 8.5mm

Stainless Steel Rigid  Tubular Heater For Manifold , Diameter 8.5mm

Product Details:

Place of Origin: China
Certification: ISO9001/CE

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: Carton or wooden crate or as per your request
Delivery Time: 10 working days or above
Payment Terms: L/C, T/T,PAYPAL
Supply Ability: 90000pcs per month
Contact Now
Detailed Product Description
Product Name: Stainless Steel Straight Tubular Heating Elements Application: Industrial Heating Elements
Sheath Material: Incoloy 800, SS 304, SS 321, SS 316 Voltage: Customized
Resistance Wire: Ni80Cr20 Power: Customized

Diameter 8.5mm Stainless Steel Rigid Tubular Heater For Manifold



Product Description



Manifold Tubular Heaters are ideal for rough daily use, reliable and easy to maintain. Formed tubular heaters are available in round and square cross sections and various sizes and shapes as per manifold's design. These types of heaters are made of stainless steel or Nicolay with sheath diameter of 8.5 mm. The heating wire is helical wounded and made of high temperature resistant Ni-Cr alloy and the insulation consists of Magnesium Oxide (MgO). The connection ends are sealed with sealing components to protect the heater from moisture.


Specification



Heat intensity

Not exceeding 30Wcm2 (advisable)

Power

Depends on the dimension

Escape of current (when cold)

<=0.1mA a 242 v.

Insulation (when cold)

5 Min Ohmios 500 Watts minimum

Dielectric strength

1500v. 1/seg

Working temperature

750ºG max.

Tolerance of length

+/-1.5%

Tolerance of diameter

-0.01 a -0.06 m/m

Tolerance of cut of connection

+/-15 mlm

Power tolerance (w)

5 % - 10 %

Cold areas

Depends on length and diameter 5-25mm



Feature



1. Simple structure
2. Long-time usage
3. High efficient heater exchange
4. It could easy to bent into many kinds of shape
5. Good insulation could withstand high voltage



Application


1. Caustic Cyanide used in gold processing
2. Hot water storage
3. Asphalt Wax
4. Caustic solutions Detergent
5. Sterilizing equipment
6. Heating oils
7. Plastic processing and packaging machinery
8. Ovens and dryers
9. Dies and Tools
10. Water& Oil heating appliances
11. Vending machines
12. Kitchen equipments
13. Medical equipments
