Kapton Insulated Conductor / Jacket Type K Thermocouple Extension Wire

Kapton Insulated Conductor / Jacket Type K Thermocouple Extension Wire

    • Kapton Insulated Conductor / Jacket Type K Thermocouple Extension Wire
    • Kapton Insulated Conductor / Jacket Type K Thermocouple Extension Wire
    • Kapton Insulated Conductor / Jacket Type K Thermocouple Extension Wire
  • Kapton Insulated Conductor / Jacket Type K Thermocouple Extension Wire

    Product Details:

    Place of Origin: China
    Brand Name: GME
    Certification: CE/UL/CSA/ISO
    Model Number: KP+KP

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000Meter
    Price: USD 0.5-3.0 FOB Shanghai /Meter
    Packaging Details: Export Carton Package
    Delivery Time: 7-15 Working Days
    Payment Terms: T/T, L/C, Western Union, PayPal
    Supply Ability: 100000Meter/Month
    Contact Now
    Detailed Product Description
    Product Name: Thermocouple Cable Max Temperature: 200℃
    Wire Size: As Customer’s Request Conductor Insulator Material: Kapton
    Jacket: Kapton Structure: KP+KP
    High Light:

    type k thermocouple extension wire

    ,

    extension grade thermocouple wire

    ,

    Kapton Insulated Conductor Thermocouple Extension Wire

    Thermocouple Compensating Cable with Kapton Insulated Conductor and Kapton Jacket (KP+KP)



    Specifications:



    1. Calibration: K, J, T, E, N, S, R

    2. Conductor insulation material: kapton

    3. Inner shield material: SSB

    4. Jacket insulation material: kapton

    5. Outer shield material: SSB

    6.  Max temperature :400℃7.

    7. Constructure : KP+KP



    Type



    Contractors

    Color Code

    K

    Wire size

    Section (mm’)

    AWG





    J

    2X1/0.2



    32

    FB+FB

    ANSI

    E

    2X1/0.5



    24

    FB+FB

    DIN

    T

    2X1/0.65



    22

    FB+FB

    IEC

    N

    2X1/0.8



    20

    FB+FB

    JIS

    S

    2X7/0.2



    24

    FB+FB

    BS



    2X7/0.3



    20

    FB+FB

    NFC







    20

    FB+FB





    Description:



    Thermocouples are widely used to measure temperature. This works on the thermoelectric effect; whereby a metal will generate a voltage when heated. By taking the differential voltage generated when two different metals in the same circuit are heated it is possible to measure changes in temperature as a change in voltage.



    In order to get an accurate measurement, expensive metals are commonly used within the temperature probe itself. For long cable runs however, the cost of these metals becomes prohibitive and for that reason Cable manufacture a range of extension and compensation cables. As standard, Cable offers Class 1 thermocouples which provide the tightest tolerance and most accurate measurements.


    Compensating cable is of different composition to extension cable (it uses alternative, cheaper alloys) but has a similar temperature. relationship over a limited range, and should only be used for joining thermocouples to their measuring instruments. It can only be used in limited ambient temperature, generally not higher than 800℃.



    Also, compensating cable is less accurate than extension cable in terms of thermal tolerance values (typically double).



    With long cable runs, the cable may need to be screened and earthed at one end (at the instrument) to minimize noise pick-up (interference) on the measuring circuit. Alternative types of screened cable construction are available and these include the use of copper or Mylar screening.



    Kapton Insulated Conductor / Jacket Type K Thermocouple Extension Wire

    Applications:



    Thermocouple extension cable consists of conductors of the same nature as the elements of the thermocouple and which extends this to the thermocouples’ reference junction.



    Commonly there are four types of insulation material for extension cable: fiberglass, , PVC and silicone. Stainless steel braided and tinned brass braided is also commonly used in the cable.

    Customers from different areas possibly require different color style for the cable, all color standard are available upon request.



    Competitive Advantage



    1. Our measurement accuracy of thermocouple cable can reach the level of grade 1
    2. 10,000 meters without joints
    3. The color-coded can meet the requirements of (ASNI, DIN, JAP, IEC ... etc)



    Contact Details
    Wuhan Global Metal Engineering Co., Ltd

    Contact Person: Frank

    Tel: +8615058960276

    Send your inquiry directly to us (0 / 3000)
