Wuhan Global Metal Engineering Co., Ltd
The pioneer manufacturer of heaters & sensors
Place of Origin: | China |
Brand Name: | GME |
Certification: | CE |
Model Number: | No |
Minimum Order Quantity: | 1 set |
---|---|
Price: | USD800/set |
Packaging Details: | wooden carton |
Delivery Time: | 5-8 working days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 1000sets |
Application: | Winding | Cooling Mode: | Air Cooling |
---|---|---|---|
Key Selling Points: | Multifunctional | Sales Service: | Online Support |
Applicable Industries: | Building Material Shops | Marking Speed: | 50 Mm/s |
High Light: | Multifunctional Coil Winding Machine,60W Coil Winding Machine,Multifunctional Coil Winding Equipment |
coil winding machine for straight hot runner heater
This is a coil winding machine to make it easier to wind coil around an object. I have been wanting to make one of these for a while and since there are some projects coming up with coils, I thought this was the best time.The machine is a very simple design with 3D printed and laser-cut parts with aluminum extrusion as the basic frame. The coils get made using Nema17 motors, all controlled by the PLEX controller with Stepper motor drivers stacked on the Controller.
Item | Technical data |
Rated power | 60W |
Voltage | 220V |
Minimum winding diameter | 15mm |
Maximum winding diameter | 25mm |
Maximum winding length | 250mm |
Package | In wooden case |
Gross weight | Around 60kg |
Size | 750x315x305mm |
