PT100 Type SS304 SS316 Robe Thermocouple For Moulds

PT100 Type SS304 SS316 Robe Thermocouple For Moulds

    • PT100 Type SS304 SS316 Robe Thermocouple For Moulds
    • PT100 Type SS304 SS316 Robe Thermocouple For Moulds
    • PT100 Type SS304 SS316 Robe Thermocouple For Moulds
    • PT100 Type SS304 SS316 Robe Thermocouple For Moulds
    • PT100 Type SS304 SS316 Robe Thermocouple For Moulds
  • PT100 Type SS304 SS316 Robe Thermocouple For Moulds

    Product Details:

    Place of Origin: China
    Brand Name: GME
    Certification: CE

    Payment & Shipping Terms:

    Minimum Order Quantity: 50pcs
    Packaging Details: cartons, pallet
    Delivery Time: 7~10 working days
    Payment Terms: T/T, Western Union, MoneyGram, L/C
    Supply Ability: 100000 pcs per Month
    Contact Now
    Detailed Product Description
    Power Source: Electric Temperature Range: -200~650℃
    Voltage: 12-480V Probe Material: SS304/SS316
    Style: K, J, S Pairs Quantity Of Element: Simplex/duplex
    Heating Element: Nichrome Resistance Mounting: Thread/flange/none
    Function: Temperature Sensor Feature: Economical
    Types Of Terminal Box: Anti-spray/water-proof Connection: Thread
    Sample: Available
    High Light:

    SS316 Robe Thermocouple

    ,

    SS304 Robe Thermocouple

    ,

    PT100 Type RTD Thermocouple

    Pt100 Type Industry probe Thermocouple for moulds


    Description:



    1) Thermocouple consists of two wires, each made of different metal, welded together at one end. When the
    welded point(measuring junction) is heated, a thermoelectromotive force is produced that is proportional
    of the temperature difference between the welded point and the other end (reference junction).


    2) Therefore, by messuring this thermoelectromotive force either with the reference junction temperature kept
    constant or by using an automatic compensation curciut, the measuring junction temperature can be measured.
    The thermoelectromotive force of a thermocouple is independent of the diameter or length of the wire used and
    depends only on the type of wire used.


    Specification:


    The thermocouples in this series can be combined with various types of materials for protection
    tubes, which prolong the life of the sensor, it makes easier the replacement of the element without
    the need of process stops.
    The thermocouple can be supplied with smooth tube, fixed bushing with thread or with adjustable
    flanges and can be assembled with analog temperature transmitter, microprocessor with or without
    communication and protocols (for more information, please feel free to contact us).





    tube diameter min 0.5mm,Default 5mm
    K type 0-1250℃
    E type 0-400℃
    PT100 0-500℃
    Thread size M8*1.25
    Spring length 70mm
    Wiring terminal 2 wire ,3 wire ,4 wire
    Stainless steel material

    Default 304 stainless steel ,customized 2520/3039/316





    PT100 Type SS304 SS316 Robe Thermocouple For Moulds
