Sheathed PT100 RTD thermocouple with Process Connection for industrial area
Description:
1) A thermocouple consists of 2 wires which are made of different metal and welded together at one end. When the welding point(measuring junction) is heated, a thermal electromotive force is produced which is proportional to the temperature difference between the welded point and the other end(reference junction).
2) Therefore, by measuring this thermal electromotive force, either with the reference junction temperature kept constant or by using an automatic compensation circuit, the measuring junction temperature can be measured. Thermal electromotive force of thermocouple is independent of the diameter of length of the wire used but depends only on the type of wire used. The thermocouple is usually fitted in insulators and enclosed in a protecting tube with terminal box and a mounting fitting.
Specification:
1, To select the appropriate length of protective paper tube and thermocouple lance according to the object and scope of the measurement
2, Attach the fastresponse immersion thermocouple to the thermocouple lance, make the pointer of the secondary instrument (or digital display) back to zero. Begin to measure.
3, It is recommended to insert the fast response immersion thermocouple into the molten steel at the depth of 300-400mm. Do not touch the furnace wall or scum. Bring up the temperature measuring gun immediately after the secondary instrument get results. The soak time of fast thermocouple in molten steel should less than 5 seconds, otherwise the lance may be burned out.
4, Change the used thermocouple into a new one, and pause for a few minutes to get ready for the next measurement.
| Code | Type | Structure | Features | Probe external diameter | |
| Single core | Double core | ||||
| 1 | Probe contact type |  |
1. Fast response 2. Not suitable for conditions with interference |
φ0.25~φ8.0 | φ3.0~φ8.0 |
| 2 | Isolation type |  |
1. Response time not as fast as probe contact type 2. Long operation life 3. Anti interference |
φ0.5~φ8.0 |
φ3.0~φ8.0 |
Application:
Thermocouples are widely used in science and industry; applications include temperature measurement for kilns, gas turbine exhaust, diesel engines, and other industrial processes. Thermocouples are also used in homes, offices and businesses as the temperature sensors in thermostats, and also as flame sensors in safety devices for gas-powered major appliances.
