Wuhan Global Metal Engineering Co., Ltd
The pioneer manufacturer of heaters & sensors
 |
| Place of Origin: | China |
| Brand Name: | GME |
| Certification: | ISO |
| Minimum Order Quantity: | 50 pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | export carton package |
| Delivery Time: | 10 working days |
| Payment Terms: | Western Union, L/C, T/T, Paypal |
| Supply Ability: | 20000 pcs/month |
| Material: | Stainless Steel | Power: | 400W |
|---|---|---|---|
| Size: | 2.2 X 4.2 X 400 Mm L | Thermocouple: | J |
| Unheating Length: | 50mm | ||
| High Light: | electric resistance heater,coil heater with thermocouple |
||
Hot runner Straight enail coil heater with J type thermocouple
Product Description:
Coil heaters are made of nickel chrome resistance wire placed inside chrome nickel steel tube filled with Mgo powder and compacted for faster and efficent heat transfer.The heaters are annealed to acquire malleability for bening into any shape.Hot runner heaters with built in thermocouple are also available.Hot runner bushes are produced with hot runner hetaers of differnt cross section with inner brass and outer stainless steel cover.It's high working temperature,fast heating,uniform heating precision,long service life,can be automatically controlled area,high thermal conduction,while internal heating material damage,external can be reuses.
Technical Detail:
1. Use condiction:environment temperature:-20~+60C,Relative temperature<95%
2. Leakage current: <0.5MA
3. Insulation resistance: ≥5MO
4. Groud resistance: <0.1O
5. Voltage resistance: no electric breakdown for 1 minute under 1500V
6. Temperature endurance: 100-1200 ℃
Application:
1. Moulds&dies
2. Manifolds
3. Hot runner nozzles and spruce bushes
4. Packaging machineries
5. Injection moulding machines nozzle
