Stainless Steel Sheath Cartridge Heater Long Life Cycle For Oil / Water

Stainless Steel Sheath Cartridge Heater Long Life Cycle For Oil / Water

    • Stainless Steel Sheath Cartridge Heater Long Life Cycle For Oil / Water
    • Stainless Steel Sheath Cartridge Heater Long Life Cycle For Oil / Water
    • Stainless Steel Sheath Cartridge Heater Long Life Cycle For Oil / Water
    • Stainless Steel Sheath Cartridge Heater Long Life Cycle For Oil / Water
  • Stainless Steel Sheath Cartridge Heater Long Life Cycle For Oil / Water

    Product Details:

    Place of Origin: China
    Brand Name: GME
    Certification: ISO/CE/UL/CSA

    Payment & Shipping Terms:

    Minimum Order Quantity: 50pcs
    Price: USD 1-100 FOB Shanghai/pc
    Packaging Details: Boxes or Wooden Cartons
    Delivery Time: 7-15 work days
    Payment Terms: D/A, D/P, T/T, Western Union, MoneyGram, L/C
    Supply Ability: 10000pcs/Month
    Contact Now
    Detailed Product Description
    Lead Wire: Silicon, Glassfiber Shealth Material: SS304 ,SS321 ,SS316
    Color: Biack And White Wattage Tolerance: +5%, -10%
    Application: Oil, Water Or Other Liquid Etc Power Source: Electric
    Voltage: 12-480v Dimension(L*W*H): Customizable
    Type: Air Heater, Cartidge Heaters Power: 1.1-6.5W/CM2
    High Light:

    cartridge immersion heater

    ,

    cartridge heater with thermocouple

    long life cycle designed stainless steel sheath Cartridge Heater for wild kind of vaurious needs

    Description:



    1) Cartridge heater is a piece of equipment, made of MgO powder or MgO tube, ceramic cap, resistance wire(NiCr2080),High temperature leads, seamless stainless steel sheath(304,321,316,800,840).



    2) usually in tube form, that is used in heating applications by way of insertion into metal blocks via a series of drilled holes. Cartridge heaters are manufactured in two basic forms - high density and low density.High density cartridge heaters are used to heat plastic injection moulds, dies, platens and so forth, whereas low density cartridge heaters are more suitable for packing machinery, heat sealing, labelling machines and hot stamping applications.


    Specification:



    1.We offer standard as well as customized models;

    2.We offer different tube diameters like 6 mm, 8 mm, 11 mm, 12.5mm, 16mm & 18mm;

    3.We offer different sheath materials. It can be availed in different materials like Incoloy 800, SS 304, SS 321, SS 316, Copper & Titanium;

    4.We offer various shapes as customer demand:immersion heater with flange or screw, explosion proof heater;

    5.Various terminal options are available;

    6.Various shapes and sizes are available;

    7.Durable and has longer life.



    Sheath material: SUS304,321,316,Incoloy800,840
    Wattage Tolerance: +5%, -10%
    Resistance tolerance: +10%, -5%
    Voltages available: 380V,240V, 220V,110V,36V,24V or 12V
    Max operating temp: 800ºC
    Length tolerance: ±1 mm
    Diameter tolerance: -0.02mm
    Standard Cold Zone: 5-10mm;
    Delivery time: 7-10 working days.
    Thermocouple Location: Type J or K are available
    Insulation resistance (cold): ≥ 500 MΩ;
    Maximum leakage current (cold): ≤ 0.5 mA;


    Stainless Steel Sheath Cartridge Heater Long Life Cycle For Oil / Water


    Application:



    1) Cartridge heaters and insertion heaters can be inserted into mould holes,



    2) used as immersion heaters placed directly in liquid or in protective wells,

    3) can be mounted in pipes or vessels. Usually, you can commonly meet or find this heaters as forllow usage-places:



    4) Plastic processing machinery. moulds and dies. hot stamping. shoe machinery. food processing machinery. packing equipment. heating gases & liquids .medical equipment,3D printer, etc.
